The Postgres foreign data wrapper (postgres_fdw
) extension can be used to retrieve or access data
on other PostgreSQL servers.
The docker-compose file in this directory sets up two PostgreSQL servers, database_1
and database_2
.
To demonstrate the use of the postgres_fdw
extension, we will create a foreign data wrapper in database_1
that connects to database_2
and accesses the managers
table. Please see the diagrams below:
+----------------+ | +----------------+
| | | | |
| Postgres | | | Postgres |
| Server 1 | | | Server 2 |
| | | | |
| database_1 | | | database_2 |
| | | | |
| +-----------+ | | | +-----------+ |
| | employees | | | | | managers | |
| +-----------+ | | | +-----------+ |
| | | | |
+----------------+ | +----------------+
| | |
| | |
| | |
| | |
| | |
| | |
+-------------------+ | +-------------------------+
| employees | | | managers |
+-------------------+ | +-------------------------+
| employee_id | | | manager_id |
| first_name | | | employee_id |
| last_name | | | experience_years |
| email | | +-------------------------+
| department | |
+-------------------+ |
+----------------+ | +----------------+
| | | | |
| Postgres | | | Postgres |
| Server 1 | | | Server 2 |
| | | | |
| database_1 | | | database_2 |
| | | | |
| +-----------+ | | | +-----------+ |
| | employees | | | | | managers | |
| +-----------+ | | | +-----------+ |
| | managers | | ----------------|----------------> | |
| | (foreign | | FDW connection | | |
| | table) | | | | |
+----------------+ | +----------------+
| | |
| | |
| | |
| | |
| | |
| | |
+-------------------+ | +-------------------------+
| employees | | | managers |
+-------------------+ | +-------------------------+
| employee_id | | | manager_id |
| first_name | | | employee_id |
| last_name | | | experience_years |
| email | | +-------------------------+
| department | |
+-------------------+ |
To run the example, execute the following command:
- Start the two PostgreSQL servers,
database_1
anddatabase_2
. The command will also launch pgAdmin on port 8001.
docker-compose up -d
- In pgAdmin, register the two servers:
database_1
:- Hostname:
db-1
- Username:
database_1
- Password:
database_1
- Hostname:
database_2
:- Hostname:
db-2
- Username:
database_2
- Password:
database_2
- Hostname:
3 Create the employees table in database_1
:
CREATE TABLE IF NOT EXISTS public.employees
(
employee_id integer NOT NULL,
first_name character varying(50),
last_name character varying(50),
email character varying(100),
department character varying(50),
CONSTRAINT employees_pkey PRIMARY KEY (employee_id)
)
- Create the managers table in
database_2
:
CREATE TABLE IF NOT EXISTS public.managers
(
manager_id integer NOT NULL,
employee_id integer,
experience_years integer,
CONSTRAINT managers_pkey PRIMARY KEY (manager_id)
)
- Insert some data into the
employees
table indatabase_1
:
INSERT INTO public.employees (employee_id, first_name, last_name, email, department) VALUES
(1, 'John', 'Doe', 'john.doe@example.com', 'Sales'),
(2, 'Jane', 'Smith', 'jane.smith@example.com', 'HR'),
(3, 'Michael', 'Johnson', 'michael.johnson@example.com', 'IT'),
(4, 'Patricia', 'Brown', 'patricia.brown@example.com', 'Finance'),
(5, 'Robert', 'Jones', 'robert.jones@example.com', 'Marketing'),
(6, 'Linda', 'Miller', 'linda.miller@example.com', 'Sales'),
(7, 'William', 'Davis', 'william.davis@example.com', 'HR'),
(8, 'Elizabeth', 'Garcia', 'elizabeth.garcia@example.com', 'IT'),
(9, 'James', 'Martinez', 'james.martinez@example.com', 'Finance'),
(10, 'Mary', 'Hernandez', 'mary.hernandez@example.com', 'Marketing');
- Insert some data into the
managers
table indatabase_2
:
INSERT INTO public.managers (manager_id, employee_id, experience_years) VALUES
(1, 1, 5),
(2, 2, 7),
(3, 3, 10),
(4, 4, 8);
- Connect to
database_1
and create the foreign data wrapper:
--- 0. Install the extension
CREATE EXTENSION postgres_fdw;
--- 1. Create the foreign server
CREATE SERVER database_2
FOREIGN DATA WRAPPER postgres_fdw
OPTIONS (host 'db-2', dbname 'database_2', port '5432');
--- 2. Create the user mapping
CREATE USER MAPPING FOR database_1
SERVER database_2
OPTIONS (user 'database_2', password 'database_2');
--- 3. Create the foreign table
CREATE FOREIGN TABLE external_managers_table
(
manager_id integer,
employee_id integer,
experience_years integer
)
SERVER database_2
OPTIONS (table_name 'managers');
- Query the
managers
table indatabase_1
:
SELECT * FROM external_managers_table;
