Goal: be done by memorial day. Which is 56 days total.
ok I missed the memorial day goal but had a much needed vacation.
Notes for each Day:
24 June https://www.hackingwithswift.com/100/swiftui/100
Final Exam: passed with merit, 94%
17 June https://www.hackingwithswift.com/100/swiftui/99
Challenges
17 June https://www.hackingwithswift.com/100/swiftui/98
Size Classes
SwiftUI gives us two environment values to monitor the current size class of our app, which in practice means we can show one layout when space is restricted and another when space is plentiful.
That will tell us whether we have a regular or compact size class. Very roughly:
- All iPhones in portrait have compact width and regular height.
- Most iPhones in landscape have compact width and compact height.
- Large iPhones (Plus-sized and Max devices) in landscape have regular width and compact height.
- All iPads in both orientations have regular width and regular height when your app is running with the full screen.
@Environment(\.horizontalSizeClass) var sizeClassyou can limit the range of Dynamic Type sizes supported by a particular view. any size up to and including .xxxLarge is fine, but nothing larger:
.dynamicTypeSize(...DynamicTypeSize.xxxLarge)15 June https://www.hackingwithswift.com/100/swiftui/97
To display two views side by side, this is done by placing two views into a NavigationView, then using a NavigationLink in the primary view to control what’s visible in the secondary view.
when we use static let for properties, Swift automatically makes them lazy –
they don’t get created until they are used.
When we use a NavigationView, by default SwiftUI expects us to provide both a primary view and a secondary detail view that can be shown side by side, with the primary view shown on the left and the secondary on the right.
On landscape iPhones that are big enough – iPhone 13 Pro Max, for example – SwiftUI’s default behavior is to show the secondary view, and provide the primary view as a slide over.
UIKit lets us control whether the primary view should be shown on iPad portrait, this is not yet possible in SwiftUI. However, we can stop iPhones from using the slide over approach if that’s what you want – try it first and see what you think. If you want it gone, add this extension
extension View {
// We need to use the @ViewBuilder attribute here because the two returned
// view types are different.
@ViewBuilder func phoneOnlyStackNavigationView() -> some View {
if UIDevice.current.userInterfaceIdiom == .phone {
self.navigationViewStyle(.stack)
} else {
self
}
}
}14 June https://www.hackingwithswift.com/100/swiftui/96
Present a sheet depending on whether an optional has a value. When the sheet disappears the optional is set back to nil.
@State private var selectedUser: User? = nil
Text("Hello, World!")
.onTapGesture {
selectedUser = User()
}
.sheet(item: $selectedUser) { user in
Text(user.id)
}.alert does the same thing, but it still needs a bool Binding:
.alert("Welcome", isPresented: $isShowingUser, presenting: selectedUser) { user in
Button(user.id) { }
}Leaving off a Button on an alert is okay, it'll show a default buton:
.alert("Welcome", isPresented: $isShowingUser) { }size classes, which is a thoroughly vague way of telling us how much space we have for our views. we have only two size classes horizontally and vertically, called “compact” and “regular”.
@Environment(\.horizontalSizeClass) var sizeClass
if sizeClass == .compact {
VStack(content: UserView.init)
} else {
HStack(content: UserView.init)
}UserView just doesn’t care – its Group simply groups the text views together without affecting their layout at all, so the layout arrangement UserView is given depends entirely on how it’s used.
Search Views
@State private var searchText = ""
NavigationView {
Text("Searching for \(searchText)")
.searchable(text: $searchText, prompt: "Look for something")
.navigationTitle("Searching")
}14 June https://www.hackingwithswift.com/100/swiftui/95
Milestone project.
13 June https://www.hackingwithswift.com/100/swiftui/94
Challenges
13 June https://www.hackingwithswift.com/100/swiftui/93
GeometryReader. This lets us read the size and position for a view at runtime, and keep reading those values as they change over time.
Absolute View Positioning
SwiftUI gives us two ways of positioning views: absolute positions using position(), and relative positions using offset()
If you want to absolute position:
Text("Hello, world!")
.position(x: 100, y: 100)when we use position() we get back a new view that takes up all available space, so it can position its child (the text) at the correct location.
If you offset some text its original dimensions don’t actually change, even though the resulting view is rendered in a different location.
Text("Hello, world")
.offset(x: 100, y: 100)
.background(.red)Frames and Coordinates in GeometryReader
In its most basic usage, what GeometryReader does is let us read the size that was proposed by the parent, then use that to manipulate our view.
we could use GeometryReader to make a text view have 90% of all available width regardless of its content:
GeometryReader { geo in
Text("Hello, World!")
.frame(width: geo.size.width * 0.9)
.background(.red)
}That geo parameter that comes in is a GeometryProxy, and it contains the proposed size, any safe area insets that have been applied, plus a method for reading frame values that we’ll look at in a moment.
GeometryReader has an interesting side effect that might catch you out at first: the view that gets returned has a flexible preferred size, which means it will expand to take up more space as needed.
coordinate spaces: the global space: measuring our view’s frame relative to the whole screen the local space: measuring our view’s frame relative to its parent
We can also create custom coordinate spaces by attaching the coordinateSpace() modifier to a view – any children of that can then read its frame relative to that coordinate space.
See LayoutAndGeometry project for code that explains this:
- A global center X of 189 means that the center of the geometry reader is 189 points from the left edge of the screen.
- A global center Y of 430 means the center of the text view is 430 points from the top edge of the screen. This isn’t dead in the center of the screen because there is more safe area at the top than the bottom.
- A custom center X of 189 means the center of the text view is 189 points from the left edge of whichever view owns the “Custom” coordinate space, which in our case is OuterView because we attach it in ContentView. This number matches the global position because OuterView runs edge to edge horizontally.
- A custom center Y of 383 means the center of the text view is 383 points from the top edge of OuterView. This value is smaller than the global center Y because OuterView doesn’t extend into the safe area.
- A local center X of 152 means the center of the text view is 152 points from the left edge of its direct container, which in this case is the GeometryReader.
- A local center Y of 350 means the center of the text view is 350 points from the top edge of its direct container, which again is the GeometryReader.
Which coordinate space you want to use depends on what question you want to answer:
- Want to know where this view is on the screen? Use the global space.
- Want to know where this view is relative to its parent? Use the local space.
- What to know where this view is relative to some other view? Use a custom space.
frame(in:) method of a GeometryProxy, SwiftUI will calculate the view’s current position in the coordinate space we ask for.
12 June https://www.hackingwithswift.com/100/swiftui/92
Layout and Geometry
All SwiftUI layout happens in three simple steps, and understanding these steps is the key to getting great layouts every time. The steps are:
- A parent view proposes a size for its child.
- Based on that information, the child then chooses its own size and the parent must respect that choice.
- The parent then positions the child in its coordinate space.
Behind the scenes, SwiftUI performs a fourth step: although it stores positions and sizes as floating-point numbers, when it comes to rendering SwiftUI rounds off any pixels to their nearest values so our graphics remain sharp.
how big is ContentView? the size of ContentView is exactly and always the size of its body, no more and no less. This is called being layout neutral: ContentView doesn’t have any size of its own, and instead happily adjusts to fit whatever size is needed.
when you apply a modifier to a view we actually get back a new view type called ModifiedContent, which stores both our original view and its modifier. This means when we apply a modifier, the actual view that goes into the hierarchy is the modified view, not the original one.
if your view hierarchy is wholly layout neutral, then it will automatically take up all available space.
applying modifiers creates new views rather than just modifying existing views in-place.
Alignment
The simplest alignment option is to use the alignment parameter of a frame() modifier.
Text("Live long and prosper")
.frame(width: 300, height: 300, alignment: .topLeading)Next option is to use a Stack with alignment:
HStack(alignment: .bottom) {If text views of differing size need to line up use
HStack(alignment: .lastTextBaseline) {alignmentGuide() modifier for custom alignments inside a Stack This takes two parameters: the guide we want to change, and a closure that returns a new alignment. The closure is given a ViewDimensions object that contains the width and height of its view, along with the ability to read its various edges.
VStack(alignment: .leading) {
Text("Hello, world!")
.alignmentGuide(.leading) { d in d[.trailing] }
Text("This is a longer line of text")
}Custom Alignment Guide
SwiftUI gives us alignment guides for the various edges of our views. However, none of these work well when you’re working with views that are split across disparate views – if you have to make two views aligned the same when they are in entirely different parts of your user interface. To fix this, SwiftUI lets us create custom alignment guides.
This should be an extension on either VerticalAlignment or HorizontalAlignment, and be a custom type that conforms to the AlignmentID protocol.
See code from today, in LayoutAndGeometry project.
28 May https://www.hackingwithswift.com/100/swiftui/91
TODO figure this one out
If you drag a card to the right but not far enough to remove it, then release, you see it turn red as it slides back to the center. Why does this happen and how can you fix it? (Tip: think about the way we set offset back to 0 immediately, even though the card hasn’t animated yet. You might solve this with a ternary within a ternary, but a custom modifier will be cleaner.)
28 May https://www.hackingwithswift.com/100/swiftui/90
More control over Haptics
Creating an instance of one of the subclasses of UIFeedbackGenerator then triggering it when you’re ready, but for more precise control over feedback you should first call its prepare() method to give the Taptic Engine chance to warm up.
Warming up the Taptic Engine helps reduce the latency between us playing the effect and it actually happening, but it also has a battery impact so the system will only stay ready for a second or two after you call prepare().
it’s OK to call prepare() then never triggering the effect – the system will keep the Taptic Engine ready for a few seconds then just power it down again. If you repeatedly call prepare() and never trigger it the system might start ignoring your prepare() calls until at least one effect has happened.
it’s perfectly allowable to call prepare() many times before triggering it once – prepare() doesn’t pause your app while the Taptic Engine warms up, and also doesn’t have any real performance cost when the system is already prepared.
while you’re testing out in small doses these haptics probably feel great – you’re making your phone buzz, and it can be really delightful. However, if you’re a serious user of this app then our haptics might hit two problems:
- The user might find them annoying, because they’ll happen once every two or three seconds depending on how fast they are.
- Worse, the user might become desensitized to them – they lose all usefulness either as a notification or as a little spark of delight.
27 May https://www.hackingwithswift.com/100/swiftui/89
SwiftUI lets us disable interactivity for a view by setting allowsHitTesting() to false.
26 May https://www.hackingwithswift.com/100/swiftui/88
Building the flashcard app
App is landscape-only, removed the portrait entries in Target -> Info
A width of 450 is no accident: the smallest iPhones have a landscape width of 480 points, so this means our card will be fully visible on all devices.
Create an array of repeating value:
var cards = [Card](repeating: Card.example, count: 10)Important stuff about order of modifiers when dragging / rotating / translating etc https://www.hackingwithswift.com/books/ios-swiftui/moving-views-with-draggesture-and-offset
24 May https://www.hackingwithswift.com/100/swiftui/87
Combine
Timer class, which is designed to run a function after a certain number of
seconds, but it can also run code repeatedly. Combine adds an extension to this
so that timers can become publishers, which are things that announce when their
value changes. @Published and ObservableObject use Combine
The following sets up a timer:
- It asks the timer to fire every 1 second.
- It says the timer should run on the main thread.
- It says the timer should run on the common run loop, which is the one you’ll want to use most of the time. (Run loops let iOS handle running code while the user is actively doing something, such as scrolling in a list.)
- It connects the timer immediately, which means it will start counting time.
- It assigns the whole thing to the timer constant so that it stays alive.
let timer = Timer.publish(every: 1, on: .main, in: .common).autoconnect()onReceive() modifier. This accepts a publisher as its first parameter and a function to run as its second, and it will make sure that function is called whenever the publisher sends its change notification.
Text("Hello, World!")
.onReceive(timer) { time in
print("The time is now \(time)")
}Canceling the timer: timer property we made is an autoconnected publisher, so we need to go to its upstream publisher to find the timer itself
timer.upstream.connect().cancel()Tolerance allows iOS to perform important energy optimization, because it can fire the timer at any point between its scheduled fire time and its scheduled fire time plus the tolerance you specify
let timer = Timer.publish(every: 1, tolerance: 0.5, on: .main, in: .common).autoconnect()the Timer class is still “best effort” – the system makes no guarantee it will execute precisely.
Detecting an app entering Foreground / Background
- Adding a new property to watch an environment value called scenePhase.
- Using onChange() to watch for the scene phase changing.
- Responding to the new scene phase somehow.
@Environment(\.scenePhase) var scenePhase
Text("Hello, world!")
.padding()
.onChange(of: scenePhase) { newPhase in
if newPhase == .active {
print("Active")
} else if newPhase == .inactive {
print("Inactive")
} else if newPhase == .background {
print("Background")
}
}- Active scenes are running right now, which on iOS means they are visible to the user. On macOS an app’s window might be wholly hidden by another app’s window, but that’s okay – it’s still considered to be active.
- Inactive scenes are running and might be visible to the user, but the user isn’t able to access them. For example, if you’re swiping down to partially reveal the control center then the app underneath is considered inactive.
- Background scenes are not visible to the user, which on iOS means they might be terminated at some point in the future.
Specific Accessibility Settings
SwiftUI gives us a number of environment properties that describe the user’s custom accessibility settings
For color blineness:
@Environment(\.accessibilityDifferentiateWithoutColor) var differentiateWithoutColoror
For reduced motion:
@Environment(\.accessibilityReduceMotion) var reduceMotion
@State private var scale = 1.0
Text("Hello, World!")
.scaleEffect(scale)
.onTapGesture {
if reduceMotion {
scale *= 1.5
} else {
withAnimation {
scale *= 1.5
}
}
}cleaning that up:
func withOptionalAnimation<Result>(_ animation: Animation? = .default, _ body: () throws -> Result) rethrows -> Result {
if UIAccessibility.isReduceMotionEnabled {
return try body()
} else {
return try withAnimation(animation, body)
}
}
.onTapGesture {
withOptionalAnimation {
scale *= 1.5
}
}Reduce Transparency
@Environment(\.accessibilityReduceTransparency) var reduceTransparency
Text()
.background(reduceTransparency ? .black : .black.opacity(0.5))23 May https://www.hackingwithswift.com/100/swiftui/86
Gestures
onTapGesture can take a count param for handling double tap etc
.onTapGesture(count: 2) {
print("Double tapped!")
}Long Press
.onLongPressGesture {
print("Long pressed!")
}
.onLongPressGesture(minimumDuration: 2) {
print("Long pressed!")
}You can even add a second closure that triggers whenever the state of the gesture has changed. This will be given a single Boolean parameter as input, and it will work like this:
- As soon as you press down the change closure will be called with its parameter set to true.
- If you release before the gesture has been recognized (so, if you release after 1 second when using a 2-second recognizer), the change closure will be called with its parameter set to false.
- If you hold down for the full length of the recognizer, then the change closure will be called with its parameter set to false (because the gesture is no longer in flight), and your completion closure will be called too.
.onLongPressGesture(minimumDuration: 1) {
print("Long pressed!")
} onPressingChanged: { inProgress in
print("In progress: \(inProgress)!")
}For more advanced gestures you should use the gesture() modifier with one of the gesture structs: DragGesture, LongPressGesture, MagnificationGesture, RotationGesture, and TapGesture. These all have special modifiers, usually onEnded() and often onChanged() too, and you can use them to take action when the gestures are in-flight (for onChanged()) or completed (for onEnded()).
attach a magnification gesture to a view so that pinching in and out scales the view up and down:
@State private var currentAmount = 0.0
@State private var finalAmount = 1.0
Text("Gesturing")
.scaleEffect(finalAmount + currentAmount)
.gesture(
MagnificationGesture()
.onChanged { amount in
currentAmount = amount - 1
}
.onEnded { amount in
finalAmount += currentAmount
currentAmount = 0
}
)Do the same but with rotation:
@State private var currentAmount = Angle.zero
@State private var finalAmount = Angle.zero
Text("Hello, World!")
.rotationEffect(currentAmount + finalAmount)
.gesture(
RotationGesture()
.onChanged { angle in
currentAmount = angle
}
.onEnded { angle in
finalAmount += currentAmount
currentAmount = .zero
}
)Gestures can clash. In this scenario the child gesture has priority:
VStack {
Text("Hello, World!")
.onTapGesture {
print("Text tapped")
}
}
.onTapGesture {
print("VStack tapped")
}This can be overridden with:
VStack {
Text("Hello, World!")
.onTapGesture {
print("Text tapped")
}
}
.highPriorityGesture(
TapGesture()
.onEnded { _ in
print("VStack tapped")
}
)Alternatively, you can use the simultaneousGesture() modifier to tell SwiftUI you want both the parent and child gestures to trigger at the same time:
VStack {
Text("Hello, World!")
.onTapGesture {
print("Text tapped")
}
}
.simultaneousGesture(
TapGesture()
.onEnded { _ in
print("VStack tapped")
}
)gesture sequences, where one gesture will only become active if another
gesture has first succeeded.
This allows you to drag a circle around, but only if you long press on it first:
// how far the circle has been dragged
@State private var offset = CGSize.zero
// whether it's being dragged
@State private var isDragging = false
let dragGesture = DragGesture()
.onChanged { value in offset = value.translation }
.onEnded { _ in
withAnimation {
offset = .zero
isDragging = false
}
}
let longPressGesture = LongPressGesture()
.onEnded { value in
withAnimation {
isDragging = true
}
}
let combined = longPressGesture.sequenced(before: dragGesture)
Circle()
.fill(.red)
.frame(width: 64, height: 64)
.scaleEffect(isDragging ? 1.5: 1)
.offset(offset)
.gesture(combined)Good Vibrations
Basics: options are .success .error .warning
func simpleSuccess() {
let generator = UINotificationFeedbackGenerator()
generator.notificationOccurred(.success)
}
Text("Hello, World!")
.onTapGesture(perform: simpleSuccess)CoreHaptics for more advanced uses
import CoreHaptics
// create an instance of CHHapticEngine, which is responsible for creating
// vibrations
@State private var engine: CHHapticEngine?
// start the haptic engine.
func prepareHaptics() {
guard CHHapticEngine.capabilitiesForHardware().supportsHaptics else { return }
do {
engine = try CHHapticEngine()
try engine?.start()
} catch {
print("There was an error creating the engine: \(error.localizedDescription)")
}
}
// configure a tap
func complexSuccess() {
// make sure that the device supports haptics
guard CHHapticEngine.capabilitiesForHardware().supportsHaptics else { return }
var events = [CHHapticEvent]()
// create one intense, sharp tap
let intensity = CHHapticEventParameter(parameterID: .hapticIntensity, value: 1)
let sharpness = CHHapticEventParameter(parameterID: .hapticSharpness, value: 1)
let event = CHHapticEvent(eventType: .hapticTransient, parameters: [intensity, sharpness], relativeTime: 0)
events.append(event)
// convert those events into a pattern and play it immediately
do {
let pattern = try CHHapticPattern(events: events, parameters: [])
let player = try engine?.makePlayer(with: pattern)
try player?.start(atTime: 0)
} catch {
print("Failed to play pattern: \(error.localizedDescription).")
}
}
// set it all up in a view
Text("Hello, World!")
.onAppear(perform: prepareHaptics)
.onTapGesture(perform: complexSuccess)Experiment further with adding more events:
for i in stride(from: 0, to: 1, by: 0.1) {
let intensity = CHHapticEventParameter(parameterID: .hapticIntensity, value: Float(i))
let sharpness = CHHapticEventParameter(parameterID: .hapticSharpness, value: Float(i))
let event = CHHapticEvent(eventType: .hapticTransient, parameters: [intensity, sharpness], relativeTime: i)
events.append(event)
}
for i in stride(from: 0, to: 1, by: 0.1) {
let intensity = CHHapticEventParameter(parameterID: .hapticIntensity, value: Float(1 - i))
let sharpness = CHHapticEventParameter(parameterID: .hapticSharpness, value: Float(1 - i))
let event = CHHapticEvent(eventType: .hapticTransient, parameters: [intensity, sharpness], relativeTime: 1 + i)
events.append(event)
}Hit Testing
SwiftUI has an advanced hit testing algorithm that uses both the frame of a view and often also its contents. For example, if you add a tap gesture to a text view then all parts of the text view are tappable – you can’t tap through the text if you happen to press exactly where a space is. On the other hand, if you attach the same gesture to a circle then SwiftUI will ignore the transparent parts of the circle.
.allowsHitTesting(false) will pass through taps to views behind it.
contentShape() modifier, which lets us specify the tappable shape for
something. eg make a circle a rectangle .contentShape(Rectangle())
For instance if a Stack has a Spacer and the Spacer is tapped, the gesture recognizer will not fire unless you give it a shape
VStack {
Text("Hello")
// will not accept taps
Spacer().frame(height: 100)
Text("World")
}
// uncomment this to allow the Spacer to accept taps
// .contentShape(Rectangle())
.onTapGesture {
print("VStack tapped!")
}22 May https://www.hackingwithswift.com/100/swiftui/85
Adding Multiple Items To A Toolbar
.toolbar {
ToolbarItemGroup(placement: .navigationBarLeading) {
// button
}
ToolbarItemGroup(placement: .navigationBarTrailing) {
// button
}
}22 May https://www.hackingwithswift.com/100/swiftui/84
Modifying state error:
Modifying state during view update, this will cause undefined behavior.
we’re telling Swift it can load our image by calling the generateQRCode() method, so when SwiftUI calls the body property it will run generateQRCode() as requested. However, while it’s running that method, we then change our new @State property, even though SwiftUI hasn’t actually finished updating the body property yet. (see MeView.swift)
On Checking Notification Permissions
we also need to be careful subsequent times because the user can retroactively change their mind and disable notifications.
One option is to call requestAuthorization() every time we want to post a notification, and honestly that works great: the first time it will show an alert, and all other times it will immediately return success or failure based on the previous response.
A more complete alternative: we can request the current authorization settings, and use that to determine whether we should schedule a notification or request permission. the settings object handed back to us includes properties such as alertSetting to check whether we can show an alert or not – the user might have restricted this so all we can do is display a numbered badge on our icon.
let addRequest = {
// setup the notification center request in here. see earlier days for info, or
code.
}
center.getNotificationSettings { settings in
if settings.authorizationStatus == .authorized {
addRequest()
} else {
center.requestAuthorization(options: [.alert, .badge, .sound]) { success, error in
if success {
addRequest()
} else {
print("could not authorize for notifications")
}
}
}
}21 May https://www.hackingwithswift.com/100/swiftui/83
textContentType() modifier tells iOS what kind of information we’re asking the
user for. This should allow iOS to provide autocomplete data on behalf of the
user.
If an array is marked with @Published, and we add or remove items from that array a change notification will be sent out. However, if we quietly change an item inside the array then SwiftUI won’t detect that change, and no views will be refreshed.
Add this to the Prospects class
func toggle(_ prospect: Prospect) {
// call send before doing anything else
objectWillChange.send()
prospect.isContacted.toggle()
}fileprivate(set), which means “this property can be read from anywhere, but only
written from the current file”
21 May https://www.hackingwithswift.com/100/swiftui/82
Using environment objects:
- Create a class for an individual entity. Class so one copy is shared.
class Prospect: Identifiable, Codable {
var id = UUID()
var name = "Anonymous"
var emailAddress = ""
var isContacted = false
}- Create an ObservableObject class that can store multiple entities as a Published property
@MainActor class Prospects: ObservableObject {
@Published var people: [Prospect]
init() {
self.people = []
}
}- Setup a StateObject in root view, add to .environmentObject, then confugure child views with EnvironmentObject to access.
// In the root view add this property
@StateObject var prospects = Prospects()
// add this to the root view, something like a TabView
.environmentObject(prospects)
// add this to all child views that need access
@EnvironmentObject var prospects: ProspectsFilter method of an array
This runs every element in a sequence through a test you provide as a closure, and any elements that return true from the test are sent back as part of a new array.
21 May https://www.hackingwithswift.com/100/swiftui/81
Context Menus
SwiftUI lets us attach context menus to objects to provide this extra functionality, all done using the contextMenu() modifier.
You can pass this a selection of buttons and they’ll be shown in order.
Text("Change Color")
.padding()
.contextMenu {
Button("Red") {
backgroundColor = .red
}
Button("Green") {
backgroundColor = .green
}
Button("Blue") {
backgroundColor = .blue
}
}Each item in a context menu can have text and an image attached to it using a Label view.
Button {
backgroundColor = .red
} label: {
Label("Red", systemImage: "checkmark.circle.fill")
}tips for when working with context menus:
- If you’re going to use them, use them in lots of places – it can be frustrating to press and hold on something only to find nothing happens.
- Keep your list of options as short as you can – aim for three or less.
- Don’t repeat options the user can already see elsewhere in your UI.
Swipe Actions
swipeActions() modifier, which lets us register one or more buttons on one or
both sides of a List row. By default buttons will be placed on the right edge of
the row, and won’t have any color.
List {
Text("Taylor Swift")
.swipeActions {
Button {
print("Hi")
} label: {
Label("Send message", systemImage: "message")
}
}
}You can customize the edge where your buttons are placed by providing an edge parameter to your swipeActions() modifier, and you can customize the color of your buttons either by adding a tint() modifier to them with a color of your choosing, or by attaching a button role.
List {
Text("Taylor Swift")
.swipeActions {
Button(role: .destructive) {
print("Hi")
} label: {
Label("Delete", systemImage: "minus.circle")
}
}
.swipeActions(edge: .leading) {
Button {
print("Hi")
} label: {
Label("Pin", systemImage: "pin")
}
.tint(.orange)
}
}Local Notifications
UserNotifications lets us create notifications to the user that can be shown on the lock screen. We have two types of notifications to work with, and they differ depending on where they were created: local notifications are ones we schedule locally, and remote notifications (commonly called push notifications) are sent from a server somewhere. You have to request permissions to send them.
import UserNotifications
// button stuff
// Request Permissions:
UNUserNotificationCenter.current().requestAuthorization(options: [.alert, .badge, .sound]) { success, error in
if success {
print("All set!")
} else if let error = error {
print(error.localizedDescription)
}
}Apple breaks them down into three parts to give it maximum flexibility:
- The content is what should be shown, and can be a title, subtitle, sound, image, and so on.
- The trigger determines when the notification should be shown, and can be a number of seconds from now, a date and time in the future, or a location.
- The request combines the content and trigger, but also adds a unique identifier so you can edit or remove specific alerts later on. If you don’t want to edit or remove stuff, use UUID().uuidString to get a random identifier.
The easiest trigger type to use is UNTimeIntervalNotificationTrigger, which lets us request a notification to be shown in a certain number of seconds from now:
let content = UNMutableNotificationContent()
content.title = "Feed the dog"
content.subtitle = "It looks hungry"
content.sound = UNNotificationSound.default
// schedule for 5s in the future
let trigger = UNTimeIntervalNotificationTrigger(timeInterval: 5, repeats: false)
// choose a random identifier
let request = UNNotificationRequest(identifier: UUID().uuidString, content: content, trigger: trigger)
// add the notifcation request
UNUserNotificationCenter.current().add(request)Swift Package Manager
go to the File menu and choose Add Packages. Enter a URL or choose from the
list. Select the Dependency Rule then add. The package will show up in the
Project Navigator under Package Dependencies and in the Project -> Info page.
20 May https://www.hackingwithswift.com/100/swiftui/80
objectWillChange
Every class that conforms to ObservableObject automatically gains a property called objectWillChange. This is a publisher, which means it does the same job as the @Published property wrapper: it notifies any views that are observing that object that something important has changed.
we have the opportunity to add extra functionality inside that willSet observer. Perhaps you want to log something, perhaps you want to call another method, or perhaps you want to clamp the integer inside value so it never goes outside of a range – it’s all under our control now.
@MainActor class DelayedUpdater: ObservableObject {
// Instead of using @Published, you can use objectWillChange
// @Published var value = 0
var value = 0 {
willSet {
objectWillChange.send()
}
}
}
// use with @StateObject as per usual
@StateObject var updater = DelayedUpdater()Run a job later:
DispatchQueue.main.asyncAfter(deadline: .now() + 1) {Result type
allows us to encapsulate either a successful value or some kind of error type, all in a single piece of data.
Instead of using do/catch like this:
func fetchReadings() async {
do {
let url = URL(string: "https://hws.dev/readings.json")!
let (data, _) = try await URLSession.shared.data(from: url)
let readings = try JSONDecoder().decode([Double].self, from: data)
output = "Found \(readings.count) readings"
} catch {
print("download error")
}
}Wrap the async work in a Task, and then access its result to determine whether
it succeeded or failed:
func fetchReadings() async {
// give Task a name so we can cancel etc
let fetchTask = Task { () -> String in
let url = URL(string: "https://hws.dev/readings.json")!
let (data, _) = try await URLSession.shared.data(from: url)
let readings = try JSONDecoder().decode([Double].self, from: data)
return "Found \(readings.count) readings"
}
// get the Task's Result
let result = await fetchTask.result
// can either get the result status in a do block:
do {
output = try result.get()
} catch {
output = "Error: \(error.localizedDescription)"
}
// or a switch statement:
switch result {
case .success(let str):
output = str
case .failure(let error):
output = "Error: \(error.localizedDescription)"
}
}the advantage of Result is that it lets us store the whole success or failure of some work in a single value, pass that around wherever we need, and read the error only when we’re ready.
Controlling Image Interpolation
Image("example")
.interpolation(.none)
.resizable()
.scaledToFit()
.frame(maxHeight: .infinity)
.background(.black)
.ignoresSafeArea()If you have an Image that is being shown scaled up (eg the image is smaller than
the frame it's in) you can turn off interpolation with .interpolation(.none)
so pixel blending doesn't happen. The resulting image is sharper with jagged
edges intead of being blurry with jagged edges.
20 May https://www.hackingwithswift.com/100/swiftui/79
HotProspects app
@State is used to work with state that is local to a single view, and how
@ObservedObject lets us pass one object from view to view so we can share it.
Well, @EnvironmentObject takes that one step further: we can place an object
into the environment so that any child view can automatically have access to it.
View chain: A -> B -> B -> D -> E ->
With @EnvironmentObject view A can put the object into the environment, view E can read the object out from the environment, and views B, C, and D don’t have to know anything happened.
environment objects use the same ObservableObject protocol you’ve already learned, and SwiftUI will automatically make sure all views that share the same environment object get updated when it changes.
If you try to load a variable with @EnvironmentObject and it does not exist,
your code will crash.
struct DisplayView: View {
@EnvironmentObject var user: User
var body: some View {
Text(user.name)
}
}
struct ContentView: View {
@StateObject private var user = User()
var body: some View {
VStack {
DisplayView().environmentObject(user)
}
}
}Environment Objects work like dictionaries: The environment effectively lets us use data types themselves for the key, and instances of the type as the value. This is a bit mind bending at first, but imagine it like this: the keys are things like Int, String, and Bool, with the values being things like 5, “Hello”, and true, which means we can say “give me the Int” and we’d get back 5.
TabView
Attach .tag modifiers to each tab to allow programmic changing of tabs.
struct ContentView: View {
@State private var selectedTab = "One"
var body: some View {
TabView(selection: $selectedTab) {
Text("Tab 1")
.onTapGesture {
selectedTab = "Two"
}
.tabItem {
Label("One", systemImage: "star")
}
.tag("One")
Text("Tab 2")
.tabItem {
Label("Two", systemImage: "circle")
}
.tag("Two")
}
}
}20 May https://www.hackingwithswift.com/100/swiftui/78
Adding a map to the Face Remember app.
Fetch a user's location:
import CoreLocation
class LocationFetcher: NSObject, CLLocationManagerDelegate {
let manager = CLLocationManager()
var lastKnownLocation: CLLocationCoordinate2D?
override init() {
super.init()
manager.delegate = self
}
func start() {
manager.requestWhenInUseAuthorization()
manager.startUpdatingLocation()
}
func locationManager(_ manager: CLLocationManager, didUpdateLocations locations: [CLLocation]) {
lastKnownLocation = locations.first?.coordinate
}
}Use it like:
struct ContentView: View {
let locationFetcher = LocationFetcher()
var body: some View {
VStack {
Button("Start Tracking Location") {
self.locationFetcher.start()
}
Button("Read Location") {
if let location = self.locationFetcher.lastKnownLocation {
print("Your location is \(location)")
} else {
print("Your location is unknown")
}
}
}
}
}20 May https://www.hackingwithswift.com/100/swiftui/77
Face Remember app.
16 May https://www.hackingwithswift.com/100/swiftui/76
challenges.
16 May https://www.hackingwithswift.com/100/swiftui/75
update old projects for accessibility
15 May https://www.hackingwithswift.com/100/swiftui/74
We can control what VoiceOver reads for a given view by attaching two modifiers: .accessibilityLabel() and .accessibilityHint(). They both take text containing anything we want, but they serve different purposes:
- The label is read immediately, and should be a short piece of text that gets right to the point. If this view deletes an item from the user’s data, it might say “Delete”.
- The hint is read after a short delay, and should provide more details on what the view is there for. It might say “Deletes an email from your inbox”, for example.
Image()
.onTapGesture { }
.accessibilityLabel(labels[selectedPicture])
.accessibilityAddTraits(.isButton)
.accessibilityRemoveTraits(.isImage)it’s important we ensure our UI removes as much clutter as possible there are several ways we can control what VoiceOver reads out. There are three in particular I want to focus on:
- Marking images as being unimportant for VoiceOver.
- Hiding views from the accessibility system.
- Grouping several views as one.
we can tell SwiftUI that a particular image is just there to make the UI look
better by using Image(decorative:). tells SwiftUI it should be ignored by
VoiceOver. .accessibilityHidden() modifier, which makes any view completely
invisible to the accessibility system:
VoiceOver sees this as two unrelated text views, and so it will either read “Your score is” or “1000” depending on what the user has selected. Both of those are unhelpful, which is where the .accessibilityElement(children:) modifier comes in: we can apply it to a parent view, and ask it to combine children into a single accessibility element:
VStack {
Text("Your score is")
Text("1000")
.font(.title)
}
.accessibilityElement(children: .combine)A better solution:
VStack {
Text("Your score is")
Text("1000")
.font(.title)
}
.accessibilityElement(children: .ignore)
.accessibilityLabel("Your score is 1000").ignore is the default parameter for children, so you can get the same results as .accessibilityElement(children: .ignore) just by saying .accessibilityElement().
We can specify custom swipe actions using accessibilityAdjustableAction()
VStack {
Text("Value: \(value)")
Button("Increment") {
value += 1
}
Button("Decrement") {
value -= 1
}
}
.accessibilityElement()
.accessibilityLabel("Value")
.accessibilityValue(String(value))
.accessibilityAdjustableAction { direction in
switch direction {
case .increment:
value += 1
case .decrement:
value -= 1
default:
print("Not handled.")
}
}14 May https://www.hackingwithswift.com/100/swiftui/73
Review and challenges.
14 May https://www.hackingwithswift.com/100/swiftui/72
MVVM: Model View View-Model
a way of getting some of our program state and logic out of our view structs. We are, in effect, separating logic from layout.
Creating ContentView-ViewModel.swift file. We’re going to use this to create a
new class that manages our data, and manipulates it on behalf of the ContentView
struct so that our view doesn’t really care how the underlying data system
works.
The main actor is responsible for running all user interface updates, and adding that attribute to the class means we want all its code – any time it runs anything, unless we specifically ask otherwise – to run on that main actor.
extension ContentView {
// this ViewModel is only for ContentView
@MainActor class ViewModel: ObservableObject {
}
}behind the scenes whenever we use @StateObject or @ObservedObject Swift was silently inferring the @MainActor attribute for us – it knows that both mean a SwiftUI view is relying on an external object to trigger its UI updates, and so it will make sure all the work automatically happens on the main actor.
However, that doesn’t provide 100% safety. Yes, Swift will infer this when used from a SwiftUI view, but what if you access your class from somewhere else – from another class, for example? Then the code could run anywhere, which isn’t safe. So, by adding the @MainActor attribute here we’re taking a “belt and braces” approach: we’re telling Swift every part of this class should run on the main actor, so it’s safe to update the UI, no matter where it’s used.
Important Caveat: if we specifcally tell the app to call this code from elsewhere it will not run on the main actor, for instance if we ask to unlock with FaceID and its callback calls code here it will not run on the main actor.
One option to fix is to create a background task, then run something on the MainActor:
Task {
await MainActor.run {
self.isUnlocked = true
}
}A better option is to tell the Task to run on the MainActor directly:
Task { @MainActor in
self.isUnlocked = true
}there will be a compiler warning about the main actor not appearing in a default value. Ignore, see this article
having all this functionality in a separate class makes it much easier to write tests for your code. Views work best when they handle presentation of data, meaning that manipulation of data is a great candidate for code to move into a view model.
Encrypting saved data. Note: this will not enforce faceid/touchid upon reading! It just encrypts at rest. Add the faceid stuff to unlock the app if it needs protecting.
let data = try JSONEncoder().encode(locations)
try data.write(to: savePath, options: [.atomic, .completeFileProtection])14 May https://www.hackingwithswift.com/100/swiftui/71
we can use + to add text views together. This lets us create larger text views that mix and match different kinds of formatting.
Text(page.title)
.font(.headline)
+ Text(": ") +
Text("Page description here")
.italic()13 May https://www.hackingwithswift.com/100/swiftui/70
BucketList app
Can determine whether to show a sheet based on an optional(!):
@State private var selectedPlace: Location?
// in view body
.sheet(item: $selectedPlace) { place in
// sheet appears when selectedPlace is not nil
// place is unwrapped inside here
// sickk
}When you have a View (sheet view in this case) that needs initial values set for
@State properties, create an initializer to set the State struct's
initialValue property:
@State private var name: String
@State private var description: String
init(location: Location) {
self.location = location
_name = State(initialValue: location.name)
_description = State(initialValue: location.description)
}To use a callback function in a view when you don't want to pass a Binding object, pass a closure with @escaping
var onSave: (Location) -> Void
init(location: Location, onsave: @escaping (Location) -> Void) {
// .. etc@escaping means the function is being stashed away for user later on, rather than being called immediately.
fixedSize() lets us bypass MapAnnotation's clipping so the text automatically grows into as much space as needed.
13 May https://www.hackingwithswift.com/100/swiftui/69
Maps
import MapKit
@State private var mapRegion = MKCoordinateRegion(
center: CLLocationCoordinate2D(latitude: 51.5, longitude: -0.12),
span: MKCoordinateSpan(latitudeDelta: 0.2, longitudeDelta: 0.2)
)
Map(coordinateRegion: $mapRegion)Annotations
- defining a new data type that contains your location
- Whatever new data type you create to store locations, it must conform to the Identifiable protocol so that SwiftUI can identify each map marker uniquely.
- creating an array of those containing all your locations
- adding them as annotations in the map
MapMarker is the most basic annotation, just a red dot:
Map(coordinateRegion: $mapRegion, annotationItems: locations) { location in
MapMarker(coordinate: location.coordinate)
}MapAnnotation allows you to customize the view:
Map(coordinateRegion: $mapRegion, annotationItems: locations) { location in
MapAnnotation(coordinate: location.coordinate) {
Circle()
.stroke(.red, lineWidth: 3)
.frame(width: 44, height: 44)
}
}
// can accept tap gestures:
MapAnnotation(coordinate: location.coordinate) {
Circle()
.stroke(.red, lineWidth: 3)
.frame(width: 44, height: 44)
.onTapGesture {
print("Tapped on \(location.name)")
}
}
// can be NavigationLinks
MapAnnotation(coordinate: location.coordinate) {
NavigationLink {
Text(location.name)
} label: {
Circle()
.stroke(.red, lineWidth: 3)
.frame(width: 44, height: 44)
}
}Securing with FaceID or TouchID
For some reason we pass the Touch ID request reason in code, and the Face ID request reason in project options.
Add to target's info Privacy - Face ID Usage Description with message about
why you need.
Then import LocalAuthentication.
- Create instance of LAContext, which allows us to query biometric status and perform the authentication check.
- Ask that context whether it’s capable of performing biometric authentication. this is important because iPod touch has neither Touch ID nor Face ID.
- If biometrics are possible, then we kick off the actual request for authentication, passing in a closure to run when authentication completes.
- When the user has either been authenticated or not, our completion closure will be called and tell us whether it worked or not, and if not what the error was.
func authenticate() {
let context = LAContext()
var error: NSError?
// check whether biometric authentication is possible
if context.canEvaluatePolicy(.deviceOwnerAuthenticationWithBiometrics, error: &error) {
// it's possible, so go ahead and use it
let reason = "We need to unlock your data."
context.evaluatePolicy(.deviceOwnerAuthenticationWithBiometrics, localizedReason: reason) { success, authenticationError in
// authentication has now completed
if success {
// authenticated successfully
} else {
// there was a problem
}
}
} else {
// no biometrics
}
}To get this to work in the simulator: go to the Features menu and choose Face ID > Enrolled, then launch the app again. This time you should see the Face ID prompt appear, and you can trigger successful or failed authentication by going back to the Features menu and choosing Face ID > Matching Face or Non-matching Face.
13 May https://www.hackingwithswift.com/100/swiftui/68
Comparable Protocol
How to sort arrays of custom structs?
- Add the Comparable conformance to the struct definition
- Add a method called
<that takes two users and returns true if the first should be sorted before the second.Operator Overloading - This method must be static
- Adding this method also gives us the
<automatically
struct User: Identifiable, Comparable {
let id = UUID()
let firstName: String
let lastName: String
static func <(lhs: User, rhs: User) -> Bool {
lhs.lastName < rhs.lastName
}
}Reading the app's Documents directory:
func getDocumentsDirectory() -> URL {
// find all possible documents directories for this user
let paths = FileManager.default.urls(for: .documentDirectory, in: .userDomainMask)
// just send back the first one, which ought to be the only one
return paths[0]
}UserDefaults is not great for storing large amounts of data. The app's
documents directory is good for this, and it is sync'd to iCloud.
write(to:) method takes three parameters:
- A URL to write to.
- Whether to make the write atomic, which means “all at once”. (usually set to true)
- What character encoding to use.
let url = getDocumentsDirectory().appendingPathComponent("message.txt")
do {
// write the string
try str.write(to: url, atomically: true, encoding: .utf8)
// read it back
let input = try String(contentsOf: url)
} catch {
outputOrError = error.localizedDescription
}turn the func into an extension:
extension FileManager {
static func userDocumentsDirectory() -> URL {
// find all possible documents directories
let paths = FileManager.default.urls(for: .documentDirectory, in: .userDomainMask)
//just use the first one, which should be the only one
return paths[0]
}
}Showing Views Conditionally
Instead of using if statements with bools, use an enum for all of the representations of state.
- The first is to define an enum for the various view states you want to represent
enum LoadingState {
case loading, success, failed
}- Next, create individual views for those states. I’m just going to use simple text views here, but they could hold anything:
struct LoadingView: View {
var body: some View {
Text("Loading...")
}
}
struct SuccessView: View {
var body: some View {
Text("Success!")
}
}
struct FailedView: View {
var body: some View {
Text("Failed.")
}
}- use this in your content view:
struct ContentView: View {
var loadingState = LoadingState.loading
var body: some View {
if loadingState == .loading {
LoadingView()
} else if loadingState == .success {
SuccessView()
} else {
FailedView()
}
}
}13 May https://www.hackingwithswift.com/100/swiftui/67
Instafilter review / Challenges.
12 May https://www.hackingwithswift.com/100/swiftui/66
12 May https://www.hackingwithswift.com/100/swiftui/65
Instafilter project
11 May https://www.hackingwithswift.com/100/swiftui/64
SwiftUI Coordinators are NOT UIKit coordinators.
SwiftUI’s coordinators are designed to act as delegates for UIKit view controllers.
SwiftUI calls makeCoordinator() when it creates an instance of a
struct conforming to UIViewControllerRepresentable is created.
// up in makeUIViewController, set the delegate to the coordinator
picker.delegate = context.coordinator // this is set by makeCoordinator()
// this is so SwiftUI knows which Coordinator to use
func makeCoordinator() -> Coordinator {
return Coordinator()
}
// Coordinator handles communication between the UIViewController
// (PHPickerViewController in this case) and SwiftUI
class Coordinator: NSObject, PHPickerViewControllerDelegate {
// add delegate methods
}Write an image to photo library and handle callbacks, objective-c style:
class ImageSaver: NSObject {
func writeToPhotoAlbum(image: UIImage) {
UIImageWriteToSavedPhotosAlbum(image, self, #selector(saveCompleted), nil)
}
@objc func saveCompleted(_ image: UIImage, didFinishSavingWithError error: Error?, contextInfo: UnsafeRawPointer) {
print("Save finished!")
}
}- Mark the method using a special compiler directive called #selector, which asks Swift to make sure the method name exists where we say it does.
- Add an attribute called @objc to the method, which tells Swift to generate code that can be read by Objective-C.
11 May https://www.hackingwithswift.com/100/swiftui/63
Images
-
UIImage, which comes from UIKit. This is an extremely powerful image type capable of working with a variety of image types, including bitmaps (like PNG), vectors (like SVG), and even sequences that form an animation. UIImage is the standard image type for UIKit, and of the three it’s closest to SwiftUI’s Image type.
-
CGImage, which comes from Core Graphics. This is a simpler image type that is really just a two-dimensional array of pixels.
-
CIImage, which comes from Core Image. This stores all the information required to produce an image but doesn’t actually turn that into pixels unless it’s asked to. Apple calls CIImage “an image recipe” rather than an actual image. There is some interoperability between the various image types:
-
We can create a UIImage from a CGImage, and create a CGImage from a UIImage.
-
We can create a CIImage from a UIImage and from a CGImage, and can create a CGImage from a CIImage.
-
We can create a SwiftUI Image from both a UIImage and a CGImage.
- We need to load our example image into a UIImage
- We’ll convert that into a CIImage, which is what Core Image wants to work with.
func loadImage() {
guard let inputImage = UIImage(named: "Example") else { return }
let beginImage = CIImage(image: inputImage)
// more code to come
}- The next step will be to create a Core Image context and a Core Image filter
import CoreImage
import CoreImage.CIFilterBuiltins
let context = CIContext()
let currentFilter = CIFilter.sepiaTone()- customize our filter to change the way it works.
currentFilter.inputImage = beginImage
currentFilter.intensity = 1- we need to convert the output from our filter to a SwiftUI Image that we can
display in our view
- Read the output image from our filter, which will be a CIImage. This might fail, so it returns an optional.
- Ask our context to create a CGImage from that output image. This also might fail, so again it returns an optional.
- Convert that CGImage into a UIImage.
- Convert that UIImage into a SwiftUI Image.
// get a CIImage from our filter or exit if that fails
guard let outputImage = currentFilter.outputImage else { return }
// attempt to get a CGImage from our CIImage
if let cgimg = context.createCGImage(outputImage, from: outputImage.extent) {
// convert that to a UIImage
let uiImage = UIImage(cgImage: cgimg)
// and convert that to a SwiftUI image
image = Image(uiImage: uiImage)
}
Using the old API: Each filter you can ask whether it supports certain parameters and apply only if so:
// ask the filter whether these params are supported and set them if so
let inputKeys = currentFilter.inputKeys
if inputKeys.contains(kCIInputIntensityKey) {
currentFilter.setValue(amount, forKey: kCIInputIntensityKey)
}UIKit 101
- UIKit has a class called UIView, which is the parent class of all views in the layouts. So, labels, buttons, text fields, sliders, and so on – those are all views.
- UIKit has a class called UIViewController, which is designed to hold all the code to bring views to life. Just like UIView, UIViewController has many subclasses that do different kinds of work.
- UIKit uses a design pattern called delegation to decide where work happens. So, when it came to deciding how to respond to a text field changing, we’d create a custom class with our functionality and make that the delegate of our text field.
Create a struct that conforms to UIViewControllerRepresentable, which builds on View but we don't need a Body property because that's handled by what UIKit returns:
struct ImagePicker: UIViewControllerRepresentable {
func makeUIViewController(context: Context) -> PHPickerViewController {
var config = PHPickerConfiguration()
config.filter = .images
let picker = PHPickerViewController(configuration: config)
return picker
}
func updateUIViewController(_ uiViewController: PHPickerViewController, context: Context) { }
}9 May https://www.hackingwithswift.com/100/swiftui/62
@State internals:
this didSet will trigger when the value is changed directly, eg in a button, but not when changed by a binding eg on a slider because bindings change the underlying struct that makes @State work, not the struct itself.
@State private var blurAmount = 0.0 {
didSet {
print("New value is \(blurAmount)")
}
}How can we ensure some code is run whenever a binding is changed, no matter how
that change happens? with the .onChange() modifier.
@State private var blurAmount = 0.0
Slider(value: $blurAmount, in: 0...20)
.onChange(of: blurAmount) { newValue in
print("New value is \(newValue)")
}confirmationDialog(): an alternative to alert() that lets us add many buttons.
confirmation dialogs slide up from the bottom, can contain multiple buttons, and can be dismissed by tapping on Cancel or by tapping outside of the options.
.confirmationDialog("Change background", isPresented: $showingConfirmation) {
Button("Red") { backgroundColor = .red }
Button("Green") { backgroundColor = .green }
Button("Blue") { backgroundColor = .blue }
Button("Cancel", role: .cancel) { }
} message: {
Text("Select a new color")
}9 May https://www.hackingwithswift.com/100/swiftui/61
Add Core Data to Day 60's project.
Update CoreData on the main thread (when mixing async/await stuff):
await MainActor.run {
// your work here
}8 May https://www.hackingwithswift.com/100/swiftui/60
FriendFace Build an app that fetches JSON from the internet and displays.
7 May https://www.hackingwithswift.com/100/swiftui/59
7 May https://www.hackingwithswift.com/100/swiftui/58
Predicates allow you to control which results should be shows from a @FetchRequest. Here universe is an attribute on Ship:
@FetchRequest(sortDescriptors: [], predicate: NSPredicate(format: "universe == 'Star Wars'")) var ships: FetchedResults<Ship>Can also provide params with %@ if strings have quotes etc:
NSPredicate(format: "universe == %@", "Star Wars"))Can also provide comparisons:
NSPredicate(format: "name < %@", "F"))Can use IN to check for values in an array:
NSPredicate(format: "universe IN %@", ["Aliens", "Firefly", "Star Trek"])Other examples
NSPredicate(format: "name BEGINSWITH %@", "E"))
// non case-sensitive version of above
NSPredicate(format: "name BEGINSWITH[c] %@", "e"))
// check whether a string contains a value
NSPredicate(format: "name CONTAINS[c] %@", "e"))
// invert with NOT
NSPredicate(format: "NOT name BEGINSWITH[c] %@", "e"))If you need more complicated predicates, join them using AND to build up as much precision as you need, or add an import for Core Data and take a look at NSCompoundPredicate – it lets you build one predicate out of several smaller ones.
Dynamic Filtering
carve off the functionality we want into a separate view, then inject values into it.
Because this view will be used inside ContentView, we don’t even need to inject a managed object context into the environment – it will inherit the context from ContentView.
In the view it needs a filter property and a custom initializer:
@FetchRequest var fetchRequest: FetchedResults<Singer>
init(filter: String) {
_fetchRequest = FetchRequest<Singer>(
sortDescriptors: [],
predicate: NSPredicate(format: "lastName BEGINSWITH %@", filter)
)
}Why the underscore on _fetchRequest? It completely replaces the existing
fetchRequest variable that's wrapped by @FetchRequest, instead of adding to
it (which would happen if we just did fetchRequest = blah). I don't fully get
this yet.
The call this new view:
FilteredView(filter: "A")To filter on any field, and for any model type, see the Want to go further?
heading here
https://www.hackingwithswift.com/books/ios-swiftui/dynamically-filtering-fetchrequest-with-swiftui
passing a filter key into a predicate:
NSPredicate(format: "%K BEGINSWITH %@", filterKey, filterValue)Data Relationships
In core data model editor, can add relationships to other entities, specifiying one to many etc in the inspector.
Need to make a custom NSManagedObject subclass for this to work with swift.
Convert NSSet to Array, so swiftui's ForEach works.
7 May https://www.hackingwithswift.com/100/swiftui/57
Can either use CoreData's generated models or have it write one out to modify
the swift file: Editor -> CreateNSManagedObject Subclass. Also open the
inspector and change Codegen to none.
Always check a managed context for changes before actually saving:
if moc.hasChanges {
try? moc.save()
}CoreData can merge duplicate objects with a merge policy
container.loadPersistentStores { description, error in
if let error = error {
print("Core Data failed to load: \(error.localizedDescription)")
return
}
self.container.viewContext.mergePolicy = NSMergePolicy.mergeByPropertyObjectTrump
}6 May https://www.hackingwithswift.com/100/swiftui/56
6 May https://www.hackingwithswift.com/100/swiftui/55
Setting up a preview when using Core Data:
jk this doesn't work. figure out why?
import CoreData
struct DetailView_Previews: PreviewProvider {
static var dataController = DataController()
static var previews: some View {
let book = Book(context: dataController.container.viewContext)
book.title = "test book"
book.author = "test author"
book.genre = "fantasy"
book.rating = 4
book.review = "test review"
return NavigationView {
DetailView(book: book)
}
}
}using a constant binding makes a view read-only
RatingView(rating: .constant(Int(book.rating)))Sort results from Core Data with a SortDescriptor (or multiple):
@FetchRequest(sortDescriptors: [
SortDescriptor(\.title),
SortDescriptor(\.author)
]) var books: FetchedResults<Book>Sorting is done in ascending order by default. To reverse:
SortDescriptor(\.title, order: .reverse)Showing an alert to confirm deletion:
.alert("Delete Book", isPresented: $showingDeleteAlert) {
Button("Delete", role: .destructive, action: deleteBook)
Button("Cancel", role: .cancel) { }
} message: {
Text("Are you sure?")
}5 May https://www.hackingwithswift.com/100/swiftui/54
constant bindings. These are bindings that have fixed values, which on the one
hand means they can’t be changed in the UI, but also means we can create them
trivially – they are perfect for previews
static var previews: some View {
RatingView(rating: .constant(4))
}3 May https://www.hackingwithswift.com/100/swiftui/53
@Binding
Lets us connect an @State property of one view to some underlying model data. It lets us store a mutable value in a view that actually points to some other value from elsewhere
@State property wrapper lets us work with local value types (structs).
@StateObject lets us work with shareable reference types (classes)
@Binding is extremely important for whenever you want to create a custom user interface component.
@Binding allows us to create a two-way connection between the view it's being declared in and the view that container the former view.
In the child view use this:
@Binding var isOn: BoolIn the parent view you'll have
@State private var rememberMe = false
// etc view stuff then when using pass as binding:
PushButton(title: "Remember Me", isOn: $rememberMe)TextEditor
be careful to make sure it doesn’t go outside the safe area, otherwise typing will be tricky; embed it in a NavigationView, a Form, or similar.
Core Data
Setup:
- defining the data we want to use in our app. Create a Data Model file
Bookworm. Give it an entity with some attributes. - writing a little Swift code to load that model and prepare it for us to use.
import CoreData
class DataController: ObservableObject {
let container = NSPersistentContainer(name: "Bookworm")
}- loadPersistentStores() on our container, which tells Core Data to access our saved data according to the data model in Bookworm.xcdatamodeld
init() {
container.loadPersistentStores { description, error in
if let error = error {
print("Core data failed to load: \(error.localizedDescription)")
}
}
}- create an instance of DataController and send it into SwiftUI’s environment
// in BookWormApp.swift, where the @main thing is
// this loads the core data model once
@StateObject private var dataController = DataController()
var body: some Scene {
WindowGroup {
ContentView()
// set the container on the Environment object
.environment(\.managedObjectContext, dataController.container.viewContext)
}
}Managed Object Contexts effectively the “live” version of your data – when you load objects and change them, those changes only exist in memory until you specifically save them back to the persistent store.
the job of the view context is to let us work with all our data in memory, which is much faster than constantly reading and writing data to disk. When we’re ready we still do need to write changes out to persistent store if we want them to be there when our app runs next, but you can also choose to discard changes if you don’t want them.
Fetch Request
Retrieving information from Core Data is done using a fetch request
@FetchRequest(sortDescriptors: []) var students: FetchedResults<Student>that creates a fetch request with no sorting, and places it into a property called students that has the the type FetchedResults.
For adding and saving objects, need access to the Managed Object Context:
@Environment(\.managedObjectContext) var mocThen can create using the class Core Data generated
let student = Student(context: moc)
try? moc.save()2 May https://www.hackingwithswift.com/100/swiftui/52
Challenges
2 May https://www.hackingwithswift.com/100/swiftui/51
Task can be used inside eg a Button, since the .task modifier can't be used
in that scenario.
Button("Place Order") {
Task {
await placeOrder()
}
}Making HTTP POST requests:
func placeOrder() async {
guard let encoded = try? JSONEncoder().encode(order) else {
print("failed to encode order")
return
}
let url = URL(string: "https://reqres.in/api/cupcakes")!
var request = URLRequest(url: url)
request.setValue("application/json", forHTTPHeaderField: "Content-Type")
request.httpMethod = "POST"
do {
let (data, _) = try await URLSession.shared.upload(for: request, from: encoded)
let decodedOrder = try JSONDecoder().decode(Order.self, from: data)
confirmationMessage = "Your order for \(decodedOrder.quantity)x \(Order.types[decodedOrder.type].lowercased()) cupcakes is on its way!"
showingConfirmation = true
} catch {
print("error uploading data")
}
}1 May https://www.hackingwithswift.com/100/swiftui/50
1 May https://www.hackingwithswift.com/100/swiftui/49
If all the properties of a type already conform to Codable, then the type itself can conform to Codable with no extra work. However, this doesn’t work when we use property wrappers such as @Published.
this compiles just fine:
class User: ObservableObject, Codable {
var name = "Paul Hudson"
}however this does not:
class User: ObservableObject, Codable {
@Published var name = "Paul Hudson"
}@Published is a struct called Published that can store any kind of value. you can’t make an instance of Published all by itself, but instead make an instance of Published – a publishable object that contains a string.
To confirm @Published to Codable, we need to tell Swift which properties should be loaded and saved, and how to do both of those actions.
This is done using an enum that conforms to a special protocol called CodingKey, which means that every case in our enum is the name of a property we want to load and save. This enum is conventionally called CodingKeys, with an S on the end, but you can call it something else if you want.
add that to the Class:
class User: ObservableObject, Codable {
// step 1: add the enum
enum CodingKeys: CodingKey {
case name
}
@Published var name = "Paul Hudson"
// step 2: create a custom initializer that will be given some sort of
container, and use that to read values for all our properties.
required init(from decoder: Decoder) throws {
let container = try decoder.container(keyedBy: CodingKeys.self)
name = try container.decode(String.self, forKey: .name)
}
// step 3: add an encoding method to do the opposite of init
func encode(to encoder: Encoder) throws {
var container = encoder.container(keyedBy: CodingKeys.self)
try container.encode(name, forKey: .name)
}
}anyone who subclasses our User class must override this initializer with a custom implementation to make sure they add their own values. We mark this using the required keyword: required init. An alternative is to mark this class as final so that subclassing isn’t allowed, in which case we’d write final class User and drop the required keyword entirely.
Asynchronous Functions
we can’t just use onAppear() here because that doesn’t know how to handle sleeping functions – it expects its function to be synchronous.
func loadData() async { }instead add a task modifier to the view:
.task {
await loadData()
}Making an HTTP Request
- parse a URL
guard let url = URL(string: "https://itunes.apple.com/search?term=taylor+swift&entity=song") else {
print("Invalid URL")
return
}2: make the request
do {
let (data, _) = try await URLSession.shared.data(from: url)
// more code to come
} catch {
print("Invalid data")
}URLSession.data(from:) returns a tuple containing the data from the request and metadata about the request.
- convert data into an struct
// this goes in 'more code to come' above
if let decodedResponse = try? JSONDecoder().decode(Response.self, from: data) {
results = decodedResponse.results
}AsyncImage
AsyncImage(url: URL(string: "https://hws.dev/img/logo.png"))Caveat: SwiftUI knows nothing about the image until our code is run and the image is downloaded, and so it isn’t able to size it appropriately ahead of time.
tell SwiftUI ahead of time that we’re trying to load a 3x scale image
AsyncImage(url: URL(string: "https://hws.dev/img/logo.png"), scale: 3)resizable() and frame() don't work because SwiftUI doesn't know what the
image looks like until it's downloaded.
Use this version of AsyncImage, which takes a closure that passes in the resulting Image view:
AsyncImage(url: URL(string: "https://hws.dev/img/logo.png")) { image in
.resizable()
.scaledToFit()
} placeholder: {
Color.red // or ProgressView()
}
.frame(width: 200, height: 200)use this version to catch any errors on download:
AsyncImage(url: URL(string: "https://hws.dev/img/bad.png")) { phase in
if let image = phase.image {
.resizable()
.scaledToFit()
} else if phase.error != nil {
Text("There was an error loading the image.")
} else {
ProgressView()
}
}
.frame(width: 200, height: 200)disabled() view modifier ... disables input views.
.disabled(username.isEmpty || email.isEmpty)
Can also make a computed property
var disableForm: Bool {
username.count < 5 || email.count < 5
}29 April https://www.hackingwithswift.com/100/swiftui/48
watching a presentation video
29 April https://www.hackingwithswift.com/100/swiftui/47
Habit tracking app challenge
29 April https://www.hackingwithswift.com/100/swiftui/46
Challenges
29 April https://www.hackingwithswift.com/100/swiftui/45
Blend modes allow us to control the way one view is rendered on top of another. The default mode is .normal, which just draws the pixels from the new view onto whatever is behind.
Multiply is so named because it multiplies each source pixel color with the
destination pixel color
The long way:
ZStack {
Image("river")
Rectangle()
.fill(.red)
.blendMode(.multiply)
}The short way:
Image("river")
.colorMultiply(.red)screen, which does the opposite of multiply: it inverts the colors, performs a
multiply, then inverts them again, resulting in a brighter image rather than a
darker image.
saturation(), which adjusts how much color is used inside a view. Give this a value between 0 (no color, just grayscale) and 1 (full color)
animatableData
When animating changes to a Shape using withAnimation { }, add an
animatableData property to the Shape. SwiftUI will pass the interpolated
values for the animation to this property so the animation actually occurs.
Otherwise it just changes directly from one value to the other.
var insetAmount: Double
var animatableData: Double {
get { insetAmount }
set { insetAmount = newValue }
}AnimatablePair
As its name suggests, this contains a pair of animatable values, and because both its values can be animated the AnimatablePair can itself be animated. We can read individual values from the pair using .first and .second.
var animatableData: AnimatablePair<Double, Double> {
get {
AnimatablePair(Double(rows), Double(columns))
}
set {
rows = Int(newValue.first)
columns = Int(newValue.second)
}
}To animate a bunch of properties chain them
AnimatablePair<CGFloat, AnimatablePair<CGFloat, AnimatablePair<CGFloat, CGFloat>>>28 April https://www.hackingwithswift.com/100/swiftui/44
CGAffineTransform, which describes how a path or view should be rotated, scaled,
or sheared; and the second is even-odd fills, which allow us to control how
overlapping shapes should be rendered.
even-odd fills:
.fill(.red, style: FillStyle(eoFill: true))
ImagePaint
dedicated type that wraps images in a way that we have complete control over how they should be rendered, which in turn means we can use them for borders and fills without problem
To use an image as a border:
Text("Hello World")
.frame(width: 300, height: 300)
.border(ImagePaint(image: Image("Example"), scale: 0.2), width: 30)drawingGroup() modifier tells swiftui to render offscren using Metal
28 April https://www.hackingwithswift.com/100/swiftui/43
Paths
To draw a triangle:
Path { path in
path.move(to: CGPoint(x: 200, y: 100))
path.addLine(to: CGPoint(x: 100, y: 300))
path.addLine(to: CGPoint(x: 300, y: 300))
path.addLine(to: CGPoint(x: 200, y: 100))
}closing paths for stroking. Either path.closeSubpath() or
.stroke(.blue, style: StrokeStyle(lineWidth: 10, lineCap: .round, lineJoin: .round))SwiftUI enables custom drawing with two subtly different types: paths and shapes. A path is a series of drawing instructions such as “start here, draw a line to here, then add a circle there”, all using absolute coordinates. In contrast, a shape has no idea where it will be used or how big it will be used, but instead will be asked to draw itself inside a given rectangle.
SwiftUI implements Shape as a protocol with a single required method: given the following rectangle, what path do you want to draw?
Triangle implemented using Shape, so it uses all free space available:
struct Triangle: Shape {
func path(in rect: CGRect) -> Path {
var path = Path()
path.move(to: CGPoint(x: rect.midX, y: rect.minY))
path.addLine(to: CGPoint(x: rect.minX, y: rect.maxY))
path.addLine(to: CGPoint(x: rect.maxX, y: rect.maxY))
path.addLine(to: CGPoint(x: rect.midX, y: rect.minY))
return path
}
}
// use with
Triangle()
.fill(.red)
.frame(width: 300, height: 300)- In the eyes of SwiftUI 0 degrees is not straight upwards, but instead directly to the right.
- Shapes measure their coordinates from the bottom-left corner rather than the top-left corner, which means SwiftUI goes the other way around from one angle to the other. This is, in my not very humble opinion, extremely alien.
- If you create a shape without a specific size, it will automatically expand to occupy all available space.
stroke(.blue, lineWidth: 10) draws like a marker half on one side of the line
half on the other. So the view may be cut off. Use strokeBorder instead, which
draws on the inside of the shape's line.
InsettableShape. This is a shape that can be inset – reduced inwards – by a
certain amount to produce another shape.
27 April https://www.hackingwithswift.com/100/swiftui/42
aspectRatio(contentMode: .fit) is the same as scaledToFit()
dateFormat allows us to specify a precise format for our dates, whereas dateStyle has a selection of built-in formats that match the user's settings.
27 April https://www.hackingwithswift.com/100/swiftui/41
Placing a VStack inside another VStack allows us to control alignment for one specific part of our view – our main mission image can be centered, while the mission details can be aligned to the leading edge.
26 April https://www.hackingwithswift.com/100/swiftui/40
Codable is needed on a struct to encode/decode JSON.
Embedded structs keep types clean and allows for namespacing.
struct CrewRole { }
struct Mission { }
// or
struct Mission {
// refer to this as Mission.CrewRole
struct CrewRole { }
}Generics
to make this generic:
func decode(_ file: String) -> [String: Astronaut] {Do this:
func decode<T>(_ file: String) -> T {Make <T> constrained to only types that are Codable:
func decode<T: Codable>Then when using the func, need to specify types (type annotation):
let astronauts: [String: Astronaut] = Bundle.main.decode("a.json")Codable is just an alias for two separate protocols: Encodable and Decodable
JSONDecoder type has a property called dateDecodingStrategy, which determines how it should decode dates. We can provide that with a DateFormatter instance that describes how our dates are formatted.
ShapeStyle protocol
Color conforms to a bigger protocol called ShapeStyle that is what lets us use colors, gradients, materials, and more as if they were the same thing.
This ShapeStyle protocol is what the background() modifier uses, so what we really want to do is extend Color but do so in a way that all the SwiftUI modifiers using ShapeStyle work too:
make an extension only if the type is Color:
extension ShapeStyle where Self == Color {To force dark mode:
.preferredColorScheme(.dark)
25 April https://www.hackingwithswift.com/100/swiftui/39
GeometryReader
When we create an Image view in SwiftUI, it will automatically size itself according to the dimensions of its contents. So, if the picture is 1000x500, the Image view will also be 1000x500.
how we can make an image fit some amount of the user’s screen width using a new view type called GeometryReader.
To resize an image this won't work:
Image("Example")
.frame(width: 300, height: 300)because the content (the image) is still bigger than the frame.
Can use clipped, but it crops the image into the frame:
Image("Example")
.frame(width: 300, height: 300)
.clipped()Can use resizable() but that squishes the image into the frame, which could
mess up the aspect ratio
Image("Example")
.resizable()
.frame(width: 300, height: 300)
To fix this we need to ask the image to resize itself proportionally, which can be done using the scaledToFit() and scaledToFill() modifiers. The first of these means the entire image will fit inside the container even if that means leaving some parts of the view empty, and the second means the view will have no empty parts even if that means some of our image lies outside the container.
// fit
Image("Example")
.resizable()
.scaledToFit()
.frame(width: 300, height: 300)
// or fill
Image("Example")
.resizable()
.scaledToFill()
.frame(width: 300, height: 300)All this works great if we want fixed-sized images, but very often you want images that automatically scale up to fill more of the screen in one or both dimensions. That is, rather than hard-coding a width of 300, what you really want to say is “make this image fill 80% of the width of the screen.”
GeometryReader is a view just like the others we’ve used, except when we create it we’ll be handed a GeometryProxy object to use. This lets us query the environment: how big is the container? What position is our view? Are there any safe area insets? And so on.
In principle that seems simple enough, but in practice you need to use GeometryReader carefully because it automatically expands to take up available space in your layout, then positions its own content aligned to the top-left corner.
An image that is 80% the width, with fixed height of 300
GeometryReader { geo in
Image("Example")
.resizable()
.scaledToFit()
.frame(width: geo.size.width * 0.8, height: 300)
}Tip: If you ever want to center a view inside a GeometryReader, rather than aligning to the top-left corner, add a second frame that makes it fill the full space of the container, like this:
GeometryReader { geo in
Image("Example")
.resizable()
.scaledToFit()
.frame(width: geo.size.width * 0.8)
.frame(width: geo.size.width, height: geo.size.height)
}ScrollView
Scroll views can scroll horizontally, vertically, or in both directions, and you can also control whether the system should show scroll indicators next to them
there’s an important catch that you need to be aware of: when we add views to a scroll view they get created immediately.
If you want to avoid this happening, there’s an alternative for both VStack and HStack called LazyVStack and LazyHStack. These will load their content on-demand – they won’t create views until they are actually shown.
there is one important layout difference: lazy stacks always take up as much as
room as is available in our layouts, whereas regular stacks take up only as much
space as is needed. Regular stacks need .frame(maxWidth: .infinity).
Horizontal ScrollView:
ScrollView(.horizontal) {
LazyHStack(spacing: 10) {Vertical ScrollView:
ScrollView {
LazyVStack(spacing: 10) {NavigationLink
NavigationLink: give this a destination and something that can be tapped and it will push a view onto the NavigationView stack
This starts with Hello, World. When tapped, it pushes Detail View onto the
stack:
NavigationView {
NavigationLink {
Text("Detail View")
} label: {
Text("Hello, world!")
.padding()
}
.navigationTitle("SwiftUI")
}JSONDecoder for custom types
Given this input
{
"name": "Taylor Swift",
"address": {
"street": "555, Taylor Swift Avenue",
"city": "Nashville"
}
}Create these structs
struct User: Codable {
let name: String
let address: Address
}
struct Address: Codable {
let street: String
let city: String
}and decode with
let data = Data(input.utf8)
let decoder = JSONDecoder()
if let user = try? decoder.decode(User.self, from: data) {
print(user.address.street)
}LazyHGrid and LazyVGrid
columns of data – a grid of information, that is able to adapt to show more data on larger screens
Creating a grid is done in two steps. First, we need to define the rows or columns we want – we only define one of the two, depending on which kind of grid we want.
vertically scrolling grid: we want our data laid out in three columns exactly 80 points wide
let layout = [
GridItem(.fixed(80)),
GridItem(.fixed(80)),
GridItem(.fixed(80))
]place your grid inside a ScrollView, along with as many items as you want. Each item you create inside the grid is automatically assigned a column in the same way that rows inside a list automatically get placed inside their parent.
ScrollView {
LazyVGrid(columns: layout) {
ForEach(0..<1000) {
Text("Item \($0)")
}
}
}fit in as many columns as possible, as long as they are at least 80 points in width:
GridItem(.adaptive(minimum: 80))set a max for more control:
GridItem(.adaptive(minimum: 80, maximum: 120))Horizontal rows:
ScrollView(.horizontal) {
LazyHGrid(rows: layout) {25 April https://www.hackingwithswift.com/100/swiftui/38
Get a users's Locale and various settings therin (currency code, language, etc) https://developer.apple.com/documentation/foundation/nslocale
24 April https://www.hackingwithswift.com/100/swiftui/37
UUID
let id = UUID()
Identifiable Protocol
means “this type can be identified uniquely.” It has only one requirement, which is that there must be a property called id that contains a unique identifier
When using, no need for id param on ForEach
JSON Decoder:
// get data from UserDefaults or wherever
JSONDecoder.decode([String].self, from: data)What is [String].self?
we’re referring to the type itself, known as the type object – we write .self
after it.
It's there so the decoder knows what type to decode into.
24 April https://www.hackingwithswift.com/100/swiftui/36
https://www.hackingwithswift.com/articles/227/which-swiftui-property-wrapper
@State monitors a var for changes and reloads the body as necessary. If a var
marked with @State is a class instead of a struct, it cannot monitor
changes since classes are mutable so the desired behavior doesn't happen.
If you want to use a class with your SwiftUI data then SwiftUI gives us three property wrappers that are useful: @StateObject, @ObservedObject, and @EnvironmentObject.
we need to tell SwiftUI when interesting parts of our class have changed. We can do this using the @Published property observer
@Published is more or less half of @State: it tells Swift that whenever either
of those two properties changes, it should send an announcement out to any
SwiftUI views that are watching that they should reload.
@StateObject, which is the other half of @State – it tells SwiftUI that we’re
creating a new class instance that should be watched for any change
announcements.
the @StateObject property wrapper can only be used on types that conform to the ObservableObject protocol.
class User: ObservableObject {
@Published var firstName = "Bilbo"
@Published var lastName = "Baggins"
}
// down in view stuff
@StateObject var user = User()As you’ve seen, rather than just using @State to declare local state, we now take three steps:
- Make a class that conforms to the ObservableObject protocol.
- Mark some properties with @Published so that any views using the class get updated when they change.
- Create an instance of our class using the @StateObject property wrapper.
When you want to use a class instance elsewhere – when you’ve created it in view A using @StateObject and want to use that same object in view B – you use a slightly different property wrapper called @ObservedObject. That’s the only difference: when creating the shared data use @StateObject, but when you’re just using it in a different view you should use @ObservedObject instead.
Sheets
Showing a sheet requires four steps:
- we need some state to track whether the sheet is showing
@State private var showingSheet = false - we need to toggle that when our button is tapped
showingSheet.toggle() - we need to attach our sheet somewhere to our view hierarchy
- we need to decide what should actually be in the sheet
.sheet(isPresented: $showingSheet) {
// contents of the sheet
SecondView()
}@Environment allows us to create properties that store values provided
to us externally. Is the user in light mode or dark mode? Have they asked for
smaller or larger fonts? What timezone are they on?
we’re effectively saying “hey, figure out how my view was presented, then dismiss it appropriately.”
struct SecondView: View {
let name: String
@Environment(\.dismiss) var dismiss
var body: some View {
Button("Hello, \(name)") {
dismiss()
}
}
}onDelete()
this is almost exclusively used with List and ForEach: we create a list of rows that are shown using ForEach, then attach onDelete() to that ForEach so the user can remove rows they don’t want
the onDelete() modifier only exists on ForEach, so if we want users to delete items from a list we must put the items inside a ForEach.
In order to make onDelete() work, we need to implement a method that will receive a single parameter of type IndexSet
ForEach(numbers, id: \.self) {
Text("Row \($0)")
}
.onDelete(perform: removeRows)
// later on make this func
func removeRows(at offsets: IndexSet) {
numbers.remove(atOffsets: offsets)
}add an Edit/Done button to the navigation bar, that lets users delete several rows more easily.
First, wrap your VStack in a NavigationView, then add this modifier to the VStack:
.toolbar {
EditButton()
}UserDefaults
One common way to store a small amount of data is called UserDefaults
everything you store in UserDefaults will automatically be loaded when your app launches – if you store a lot in there your app launch will slow down. To give you at least an idea, you should aim to store no more than 512KB in there.
SwiftUI can often wrap up UserDefaults inside a nice and simple property wrapper called @AppStorage – it only supports a subset of functionality right now, but it can be really helpful.
UserDefaults.standard.set(self.tapCount, forKey: "Tap")- use UserDefaults.standard. This is the built-in instance of UserDefaults that is attached to our app, but in more advanced apps you can create your own instances. For example, if you want to share defaults across several app extensions you might create your own UserDefaults instance
- There is a single set() method that accepts any kind of data – integers, Booleans, strings, and more.
- We attach a string name to this data, in our case it’s the key “Tap”. This key is case-sensitive,
- it takes iOS a little time to write your data to permanent storage
Reading back out:
@State private var tapCount = UserDefaults.standard.integer(forKey: "Tap")if the key can’t be found it just sends back 0.
@AppStorage
SwiftUI provides an @AppStorage property wrapper around UserDefaults:
struct ContentView: View {
@AppStorage("tapCount") private var tapCount = 0
var body: some View {
Button("Tap count: \(tapCount)") {
tapCount += 1
}
}
}- access to the UserDefaults system is through the @AppStorage property wrapper. This works like @State: when the value changes, it will reinvoked the body property so our UI reflects the new data.
- We attach a string name, which is the UserDefaults key where we want to store the data
right now at least @AppStorage doesn’t make it easy to handle storing complex objects such as Swift structs
Codable
Codable: a protocol specifically for archiving and unarchiving data
When working with a type that only has simple properties – strings, integers, Booleans, arrays of strings, and so on – the only thing we need to do to support archiving and unarchiving is add a conformance to Codable.
let encoder = JSONEncoder()
if let data = try? encoder.encode(user) {
UserDefaults.standard.set(data, forKey: "UserData")
}23 April https://www.hackingwithswift.com/100/swiftui/35
Multiplication Tables game.
23 April https://www.hackingwithswift.com/100/swiftui/34
22 April https://www.hackingwithswift.com/100/swiftui/33
only changes that occur before the animation() modifier get animated
if we apply multiple animation() modifiers, each one controls everything before it up to the next animation
it’s possible to disable animations entirely by passing nil to the modifier
.animation(nil, value: enabled)
.offset modifier adjusts the x and y offset of a view.
DragGesture
Drag gestures have two extra modifiers that are useful to us here: onChanged() lets us run a closure whenever the user moves their finger, and onEnded() lets us run a closure when the user lifts their finger off the screen, ending the drag
// @State private var dragAmount = CGSize.zero
.gesture(
DragGesture()
.onChanged { dragAmount = $0.translation }
.onEnded { _ in dragAmount = .zero }
)implicitly animate both the dragging and the snapping back:
.animation(.spring(), value: dragAmount)
explicitly animate the snap back:
.onEnded { _ in
withAnimation(.spring()) {
dragAmount = .zero
}
}customize the way views are shown and hidden with transitions.
use .transition to change how a view animates.
use asymmetric to use one transition during showing, another during hiding
.transition(.asymmetric(insertion: .scale, removal: .opacity))
Creating custom transitions
rotationEffect() is similar to rotation3DEffect(), except it always rotates around the Z axis. it also gives us the ability to control the anchor point of the rotation
21 April https://www.hackingwithswift.com/100/swiftui/32
scaleEffect() modifier:
provide this with a value from 0 up, and it will be drawn at that size – a value of 1.0 is equivalent to 100%, i.e. the button’s normal size
create an implicit animation for our changes so that all the scaling happens
smoothly by adding an animation() modifier to the button.
.animation(.default, value: animationAmount)
That implicit animation takes effect on all properties of the view that change
ease in, ease out animation by default.
other options exist
.animation(.easeOut, value: animationAmount)
Spring animation
.animation(.interpolatingSpring(
stiffness: 50,
damping: 1
),
value: animationAmount)change the duration
.animation(.easeInOut(duration: 2), value: animationAmount)
can also set a delay
.animation(
.easeInOut(duration: 2)
.delay(1), // delay is another modifier
value: animationAmount
)repeat animations:
.animation(
.easeInOut(duration: 1)
.repeatCount(3, autoreverses: true),
value: animationAmount
)continuous
.animation(
.easeInOut(duration: 1)
.repeatForever(autoreverses: true),
value: animationAmount
)Can add overlays to views, and animate forever with onAppear:
.overlay {
Circle()
.stroke(.red)
.scaleEffect(animationAmount)
.opacity(2 - animationAmount)
.animation(
.easeOut(duration: 1)
.repeatForever(autoreverses: false),
value: animationAmount
)
}
.onAppear {
animationAmount = 2
}The animation() modifier can be applied to any SwiftUI binding, which causes the value to animate between its current and new value
Can bind a stepper to an animation:
@State private var animationAmount = 1.0
// view body stuff
Stepper("Scale amount", value: $animationAmount.animation(), in: 1...10)SwiftUI is examining the state of our view before the binding changes, examining the target state of our views after the binding changes, then applying an animation to get from point A to point
Can bind animations directly by adding a modifier to a view:
Stepper("Scale amount", value: $animationAmount.animation(
.easeInOut(duration: 1)
.repeatCount(3, autoreverses: true)
), in: 1...10)rotation3DEffect(), which can be given a rotation amount in degrees as well as an axis that determines how the view rotates
.rotation3DEffect(.degrees(animationAmount), axis: (x: 0, y: 1, z: 0))
If we just write animationAmount += 360 then the change will happen immediately, because there is no animation modifier attached to the button. This is where explicit animations come in: if we use a withAnimation() closure then SwiftUI will ensure any changes resulting from the new state will automatically be animated.
withAnimation(.interpolatingSpring(stiffness: 5, damping: 1)) {
animationAmount += 360
}20 April https://www.hackingwithswift.com/100/swiftui/31
20 April https://www.hackingwithswift.com/100/swiftui/30
when the user presses return on the keyboard, and in SwiftUI we can do that by adding an onSubmit() modifier somewhere in our view hierarchy – it could be directly on the button, but it can be anywhere else in the view because it will be triggered when any text is submitted
Disable auto caps on a TextField with .autocapitalization(.none).
SF Symbols provides numbers in circles from 0 through 50, all named using the format “x.circle.fill” – so 1.circle.fill, 20.circle.fill.
Image(systemName: "\(word.count).circle")
Animate an action (this is in a func. will cover animations later)
withAnimation {
usedWords.insert(answer, at: 0)
}When we call fatalError() it will – unconditionally and always – cause our app to crash
SwiftUI gives us a dedicated view modifier for running a closure when a view is shown:
.onAppear(perform: startGame)19 April https://www.hackingwithswift.com/100/swiftui/29
List is a workhorse. UITableView equvalent. Form, except form is for user
input. Can have Sections. Style with .listStyle
one thing List can do that Form can’t is to generate its rows entirely from dynamic content without needing a ForEach.
List(0..<5) {
Text("Dynamic row \($0)")
}Fetching files from the app bundle
if let fileURL = Bundle.main.url(forResource: "some-file", withExtension: "txt") {
// we found the file in our bundle!
if let fileContents = try? String(contentsOf: fileURL) {
// we loaded the file into a string!
// NOTE: do this in a do/catch block
}
}Separating a string into an array of components
let input = "a b c"
let letters = input.components(separatedBy: " ")
// output is ['a', 'b', 'c']
// can get a random element
letters.randomElement() // returns Optional String
// trim whitespace
let trimmed = letter?.trimmingCharacters(in: .whitespacesAndNewlines)Spell check
let word = "swift"
let checker = UITextChecker() // this is an objective-c API
// convert a swift string into an objective-c range
let range = NSRange(location: 0, length: word.utf16.count)
// That sends back another Objective-C string range, telling us where the
// misspelling was found.
let misspelledRange = checker.rangeOfMisspelledWord(
in: word,
range: range,
startingAt: 0,
wrap: false,
language: "en"
)
// obj-c doesn't have the concept of optionals, so need to check for nil
let allGood = misspelledRange.location == NSNotFound18 April https://www.hackingwithswift.com/100/swiftui/28
18 April https://www.hackingwithswift.com/100/swiftui/27
18 April https://www.hackingwithswift.com/100/swiftui/26
Steppers
can provide a limit on their range with in: 2...4 param
can provide a step by which to change with each tap step: 0.25
use .formatted() on a Double to make it look nice
DatePicker and Date
use .labelsHidden() modifier to hide the DatePicker label but keep the text
description for screen readers.
note: selection: $binding seems to be how two way bindings take args
(TextField and DatePicker for eg) but sometimes it's value: $binding
use displayedComponents: to determine which DatePicker UI to show.
use in: to limit the date input range. To create a range of Dates:
let tomorrow = Date.now.addingTimeInterval(86400)
let range = Date.now...tomorrowSwift has one-sided ranges too:
let range = Date.now...Use DateComponents instead of Date to modify different parts of a Date:
var components = DateComponents()
components.hour = 8
components.minute = 0
let date = Calendar.current.date(from: components)
// date(from:) returns an Optional Date. Use nil coalescing:
let date = Calendar.current.date(from: components) ?? Date.nowTo pull out specific components from a Date:
let components = Calendar.current.dateComponents([.hour, .minute], from:
someDate)
// each component is an Optional
let hour = components.hour ?? 0
let minute = components.minute ?? 0
Date takes a formatter, which is locale-specific:
Text(Date.now, format: .dateTime.day().month().year())
// or
Text(Date.now.formatted(date: .long, time: .shortened))
CreateML
tabular regression
throw a load of spreadsheet-like data at Create ML and ask it to figure out the relationship between various values
target: which is the value we want the computer to learn to predict, and the
features: which are the values we want the computer to inspect in order to
predict the target
CreateML For Everyone: https://youtu.be/a905KIBw1hs
16 April https://www.hackingwithswift.com/100/swiftui/25
Review classes v structs bindings https://www.hackingwithswift.com/guide/ios-swiftui/2/2/key-points https://www.hackingwithswift.com/guide/ios-swiftui/2/1/what-you-learned
Rock Paper Scissors game build
16 April https://www.hackingwithswift.com/100/swiftui/24
challenges
16 April https://www.hackingwithswift.com/100/swiftui/23
Don't try to change what is 'behind' a view eg the background. Change the view
itself with a modifier, using .frame and .background.
Whenever we apply a modifier to a SwiftUI view, we actually create a new view with that change applied – we don’t just modify the existing view in place.
Order matters with modifiers. Set a frame first.
TupleView is what you get internally when multiple views are returned in a
group like a stack. The max views is 10 per group because ToupleView only has
support for 2-10 views inside.
Swift silently applies a special attribute to the body property called @ViewBuilder. This has the effect of silently wrapping multiple views in one of those TupleView containers, so that even though it looks like we’re sending back multiple views they get combined into one TupleView.
Can use ternary operator to control modifier properties.
You can often use regular if conditions to return different views based on some state, but this actually creates more work for SwiftUI
Environment vs regular modifiers:
Many modifiers can be applied to containers, which allows us to apply the same modifier to many views at the same time.
Containers are vstack group etc
This is called an environment modifier, and is different from a regular modifier that is applied to a view.
there is no way of knowing ahead of time which modifiers are environment modifiers and which are regular modifiers other than reading the individual documentation for each modifier and hope it’s mentioned
Views can be set as properties on a struct to be re-used in Body, but not
really ideal
https://www.hackingwithswift.com/books/ios-swiftui/views-as-properties
It's very efficient to break up views to DRY code.
To create a custom modifier, create a new struct that conforms to the ViewModifier protocol
struct Title: ViewModifier {
func body(content: Content) -> some View {
content
.font(.largeTitle)
}
}best to create these as extensions on View though
extension View {
func titleStyle() -> some View {
modifier(Title())
}
}custom view modifiers can have their own stored properties, whereas extensions to View cannot.
15 April https://www.hackingwithswift.com/100/swiftui/22
15 April https://www.hackingwithswift.com/100/swiftui/21
13 April https://www.hackingwithswift.com/100/swiftui/20
If you want some View to show multiple views, you have to wrap them first.
Otherwise doing something like this will give you two screens:
var body: some View {
Text("one")
Text("two")
}To get around that, use groups like nav controllers or stacks.
Vertical and horizontal stacks automatically fit their content, and prefer to align themselves to the center of the available space. If you want to change that you can use one or more Spacer views to push the contents of your stack to one side.
ZStack draws its contents from top to bottom, back to front
To set a background on an entire view, set it in a ZStack and add Color.red or w/e as the first view.
Colors take up all space available, but can add a frame on them.
Use .ignoresSafeArea() to draw into the entire screen even around the notch
Use foregroundStyle and foregroundColor to allow a background through or
not.
Important: Apple explicitly recommends against using too many prominent buttons, because when everything is prominent nothing is.
You can pass a custom label to a Button's trailing closure to customize it. This is typically used when you want an image to be the background.
when should an alert be shown and how? Views are a function of our program state, and alerts aren’t an exception to that. So, rather than saying “show the alert”, we instead create our alert and set the conditions under which it should be shown.
any button inside an alert will automatically dismiss the alert
add trailing closure to alert to add additional message.
13 April https://www.hackingwithswift.com/100/swiftui/19
Can do unit conversions with this: https://developer.apple.com/documentation/foundation/dimension
12 April https://www.hackingwithswift.com/100/swiftui/18
WeSplit review and challenges.
To store a TextField formatter:
var currencyFormat: FloatingPointFormatStyle<Double>.Currency {
FloatingPointFormatStyle<Double>.Currency(code: Locale.current.currencyCode ?? "USD")
}12 April https://www.hackingwithswift.com/100/swiftui/17
WeSplit app.
TextField(blah, value: number, format: .currency())
To determine focus and show/hide keyboard based on that, first add a
@FocusState property, then add a .focused($isFocused) modifier to the
TextField, then add a toolbar to the NavigationView with a done button to set
isFocused to false. This button has a placement of .keyboard so it only
shows up with the keyboard.
11 April https://www.hackingwithswift.com/100/swiftui/16
View protocol has one requirement: a computed property called Body that returns
some View
Modifiers (
.padding()for instance) return the original View plus the extra modification you asked for.
option + command + P to restart the Preview
SwiftUI has a limit of 10 children views per parent view. Get around it with Group. Groups don't change things visually.
Use Section to split the view visually.
Safe Area keeps views out of eg the menu bar. Use a NavigationView to keep
content from scrolling up there.
Navigation Titles are added to children of NavigationView
"Views are a function of their state"
Property Wrappers allow struct properties to eg be mutable even though they're
in a Struct. @State allows a property to be stored by SwiftUI somewhere that
it can be modified. Recommended to use private with these.
Two-way bindings: when a view needs to write back a value that it's also
reading. Done with $ in front of the var name eg
TextField("hi", text: $name)
ForEach creates views in a loop. Another way to get around the 10 child view
limit.
10 April https://www.hackingwithswift.com/100/swiftui/15
Swift review, before getting into SwiftUI https://www.hackingwithswift.com/articles/242/learn-essential-swift-in-one-hour
10 April https://www.hackingwithswift.com/100/swiftui/14
Optionals
Three ways to unwrap:
if letguard let- nil coalescing
??
10 April https://www.hackingwithswift.com/100/swiftui/13
Protocols and Extensions
if you’re returning a new value rather than changing it in place, you should use word endings like ed or ing, like reversed(). reverse() would change in place.
9 April https://www.hackingwithswift.com/100/swiftui/12
Classes
9 April https://www.hackingwithswift.com/100/swiftui/11
struct access control, static properties and methods
9 April https://www.hackingwithswift.com/100/swiftui/10
Structs, computed properties, property observers, initializers
8 April https://www.hackingwithswift.com/100/swiftui/9
Closures
7 April https://www.hackingwithswift.com/100/swiftui/8
Error handling
7 April https://www.hackingwithswift.com/100/swiftui/7
Functions
7 April https://www.hackingwithswift.com/100/swiftui/6
Loops
7 April https://www.hackingwithswift.com/100/swiftui/5
Conditionals
6 April https://www.hackingwithswift.com/100/swiftui/4
6 April https://www.hackingwithswift.com/100/swiftui/3
Arrays
// create explicitly with generic syntax
var scores = Array<Int>()
// create with array syntax
var albums = [String]()
var albums: [String] = ["Red"]
// or implicitly
var names = ["brian"]
// remove at an index
names.remove(at: 0)
names.removeAll()
names.reverse()Dictionaries
// create with dictionary syntax
var heights = [String: Int]()
heights["Yao Ming"] = 229
// this returns an Optional Int
heights["Yao Ming"]
// to receive an Int
heights["Yao Ming", default: 0]Sets
// implicit, from an array.
let people = Set(["brian", "sara", "price"])
// or
let people = Set<String>()
people.insert("brian")Enums
enum Weekday {
case monday, tuesday, wednesday, thursday, friday
}
var day = Weekday.monday
day = .tuesday // shorthand, swift knows day's type
