Makerpad_Pro_Software

MakerPad Pro is an ESP32-powered SmartScreen Hub with a 3.5-inch touchscreen display offering vivid visuals and a 2 MP camera for image related applications. Ideal for IoT projects and creative DIY electronics.

This GitHub provides getting started guides for Makerpad Pro.

Features :

ESP32-WROVER-B module which generic Wi-Fi + Bluetooth® + Bluetooth LE MCU modules that target a wide variety of applications
Camera for photography related applications
Capacitive Touch Display 3.5” for user interaction
Onboard micro SD card storage support for Data logging
Buzzer for adding audio alert for project
Type C interface for programming/power
GPIO pins breakout for interfacing additional peripherals if camera not used
Boot and Reset Button
Open source LVGL is supported for designing rich GUI for embedded applications.

Specifications :

ESP32-WROVER-B contains low-power Xtensa® 32-bit LX6 microprocessors, 448 KB of ROM and 520 KB of on-chip SRAM, with 8MB flash and 8MB PSRAM
WiFi protocols 802.11 b/g/n and Bluetooth v4.2 BR/EDR and Bluetooth LE
OV2640 camera built-in having 2M pixel with lens 1/4"
Camera Pixel Size 2.2 µm x 2.2 µm
Camera Supports image sizes: UXGA, SXGA, SVGA, and any size scaling down from SXGA to 40x30
Display Resolution is 320x480 pixel
TFT LCD driver is ILI9488
FT6236 Series capacitive touch panel controller IC
Board Supply voltage 5V
Operating voltage of GPIO pins 3.3V
Operating Temperature: -30°C to 70°C
Stable Image : 0°C to 50°C

Pinouts :

(1) Camera
(2) 3.5” Touch Display
(3) Reset Button
(4) Boot Button
(5) Power Status LED
(6) Type C
(7) TF card slot
(8) GPIOs breakout*
(9) Buzzer
(10) ESP32-WROVER-B module

*Note: Use only camera or breakout GPIOs pin at a time.

Interfacing Details :

Camera (OV2640) interfacing with ESP32

ESP32	Camera	Function
IO5	D0/Y2	Data Pin, for transferring image data from the camera to the ESP32
IO18	D1/Y3	Data Pin
IO19	D2/Y4	Data Pin
IO21	D3/Y5	Data Pin
IO36	D4/Y6	Data Pin
IO39	D5/Y7	Data Pin
IO34	D6/Y8	Data Pin
IO35	D7/Y9	Data Pin
IO32	XCLK	External Clock, for synchronizing data transfer
IO22	PCLK	Pixel Clock, signals the start of each pixel's data
IO25	VSYNC	Vertical Synchronization, marks the beginning of a new frame or image
IO23	HREF	Horizontal Reference, indicates the start of a new line or row of pixels
IO26	SSCB_SDA	Serial Data line for I2C bus communication, for camera configuration and control
IO27	SSCB_SCL	Serial Clock line for I2C bus communication
-	PWDN	Power-Down Pin
-	RESET	Reset pin, connected to ESP reset pin

SDcard interfacing with ESP32

ESP32	Display	Function
IO14	CLK	SPI Clock pin for SDcard
IO13	MOSI	MOSI (Master OUT Slave IN) pin of SPI interface for SDcard
IO12	MISO	MISO (Master IN Slave OUT) pin of SPI interface for SDcard
IO4	CS	SPI Chip Select pin for SDcard

Display (ILI9488) interfacing with ESP32

ESP32	Display	Function
IO14	CLK	SPI Clock pin for Display
IO13	MOSI	MOSI (Master OUT Slave IN) pin of SPI interface for Display
IO12	MISO	MISO (Master IN Slave OUT) pin of SPI interface for Display
IO15	CS	SPI Chip Select pin for Display
IO26	RST	Display Reset pin
IO33	D/C	Data/Command pin of Display
-	BL	Direct supply to Backlight of display

ESP32 and Touch (FT6236) controller interfacing

ESP32 FT6236 Touch Function

IO26 SDA Serial Data pin of I2C communication

IO27 SCL Serial Clock of I2C communication
Buttons and Buzzer Interfacing with ESP32

ESP32 Hardware Function

IO2 Buzzer HIGH - Turn ON, LOW - Turn OFF

IO0 BOOT Boot button

ESP32	FT6236 Touch	Function
IO26	SDA	Serial Data pin of I2C communication
IO27	SCL	Serial Clock of I2C communication

ESP32	Hardware	Function
IO2	Buzzer	HIGH - Turn ON, LOW - Turn OFF
IO0	BOOT	Boot button

GPIOs Breakout Pins

Breakout Pins	Function
3V3	3.3V Positive Supply
GND	Ground Supply Pin
5V	5V Positive Supply
IO5	GPIO5, VSPICS0, HS1_DATA6, EMAC_RX_CLK
IO18	GPIO18, VSPICLK, HS1_DATA7
IO19	GPIO19, VSPIQ, U0CTS, EMAC_TXD0
IO21	GPIO21, VSPIHD, EMAC_TX_EN
IO23	GPIO23, VSPID, HS1_STROBE
IO22	GPIO22, VSPIWP, U0RTS, EMAC_TXD1
IO34	GPIO34, ADC1_CH6, RTC_GPIO4

NOTE: GPIO breakout pins are shared with the Camera, so only use one at a time.

1. Configure and Setup Development Environment

Download Arduino IDE from official site and install into your system. We have use Arduino IDE 1.8.19
Once installation done will add ESP32 board support into IDE, for this first you need to add below link into preference:
```
https://raw.githubusercontent.com/espressif/arduino-esp32/gh-pages/package_esp32_index.json
```
Select File > Preference, and add link as show in below image,
Now will install ESP32 based different boards as shown in below image, you may get new version option but select 1.0.5 version which is compatible for Makerpad Pro
Once done, keeping default settings select the ESP32 WROVER Module with suitable com port (may be different in your case) as shown below,

2. Installing Libraries

Download library zip file provided here in github.
Extract and copy files inside Document > Arduino > Libraries folder. Make sure to restart Arduino IDE whenever you update or add any libraries.
Above library folder contains two files TFT_eSPI and FT6236 with pre-configured settings for Makerpad Pro
Along with this you will also have to install LovyanGFX Library version 0.3.8 into arduino, steps shown in below image:
Make sure you have install above mentioned all libraries for successful compilation of demo examples code provided in GitHub for Makerpad Pro.

3. Testing First Code

At this step you are all set to test codes, for easy getting started we have provided various demo example codes in github which you can download and try.
Open one example code in Arduino and make sure you have selected correct board with suitable com port, click on upload button to transfer code on ESP32 of Makerpad Pro. Make sure to press Boot button to begin upload process (in terminal you see message -> Connecting....____ ) as shown in below image.
Checkout other examples below and build your own custom program codes using those references.

Example Codes

Example 1 : Simple Buzzer test code
Example 2 : Display Object demo code working with TFT_eSPI graphics library.
Example 3 : Click Photos Demo code to test camera, touch and SD card combine.
Example 4 : Try out Simple Paint App on Makerpad Pro
and Many more...

Now you are ready to try out your own codes, Happy Coding!

4. How to setup and use LVGL UI with Makerpad Pro

Follow below provided step by step guide to configure, develop and use LVGL UI on Makerpad Pro. To follow along instructions you can download and install Squareline Studio App.
