PHONK

🎉 Hello! I'm happy to see you here reading about PHONK!!

PHONK is a self-contained creative scripting toolbox for new and old Android devices. Create scripts rapidly from your phone or using the remote Web Editor on your computer. The API is simple and extensive. GUI, audio, graphics, bluetooth ble, arduino, OSC, midi, and much more.

Have a look in the PHONK website for more info

Features

Takes 1 min to setup on your phone.
No need to install anything on your computer
PHONK Uses Javascript but it calls native Java functions, getting close to native speed.
Simplified API. Create custom interfaces and access on-device sensors in a couple of lines of code
Pseudo Live Coding (Select your code and Control (or Cmd) + Shift + X to live execute)
Bluetooth and Arduino in a few lines of code
MQTT, Http requests, Websockets, OSC, Midi
Access to Processing.org API
Use your PureData skills thanks to the embed LibPd
OpenStreetMaps and muuuch more!

How to install it

Get it from

APK
~~F-droid~~ (Need help)
Play Store
or just compile it your self

If you have an Android phone with a version higher than 4.1 (that's from 2012!) then it should work! If you find a problem, please create an issue.

During the first install, the app will

Ask you for a bunch of permissions. I recommend accepting all of them to be able to run the examples. You can always revoke them :)
Install the examples in the device "sdcard" folder. Doing this we can easily access the examples and self-made scripts from any other app.

How to create your first script

Check the Getting started guide for a more detailed explanation

Run the PHONK app in your Android device. You can create your first script within the device although it might be a bit cumbersome using the device virtual keyboard.

Instead, connect your computer and Android to the same Wifi network. On your computer open the browser and type the ip address indicated on your phone after pressing "Start web editor". A web editor will load allowing you to code on the phone.

You can create a new project and copy and paste this into the editor.

// ui elements need x, y, w, h normalized paramaters
ui.addButton('Start accelerometer', 0.1, 0.45, 0.8, 0.1).onClick(function () {
  sensors.accelerometer.start()
})

sensors.accelerometer.onChange(function (e) {
  console.log(e.x, e.y, e.z)
})

Now run the project. 🎉

You can explore the variety of examples included in PHONK and modify them in order to explore its capabilities.

Compile it yourself

PHONK depends on 3 subprojects. Each of them is on a different repository so things are a bit easy to manage.

The main PHONK Android project. (this repo)
The Web Editor https://github.com/victordiaz/phonk-editor
The examples https://github.com/victordiaz/phonk-examples

In order to compile PHONK you should fetch the 3 repos so they follow the following folder structure.

phonk_project
 ├ phonk # the Android project
 ├ phonk-editor
 └ phonk-examples

Once you fetched all projects, you should

Copy the examples to the assets android assets folder. Go to the phonk-examples folder and run npm run cleanAndDeploy
Add the Web Editor to the Android app asset folder. Go to the phonk-editor folder, npm install to install the Web Editor dependencies and finally run npm run buildAndDeploy to build the Web Editor and copy
In Android Studio import the phonk folder and build the project.

Once you've done that, there is not neccessity to do the first steps anymore unless you want to update the Web Editor or the examples.

Project structure

The PHONK app is divided into two modules phonk_app and phonk_apprunner.

phonk_app is the app that you see when you start PHONK and manages all the stuff to let you makes projects.
phonk_apprunner is the part in charge of running the scripts and contains all the API. If you want to add or improve the API you can go to the folder phonk/phonk_apprunner/src/main/java/io/phonk/runner/apprunner/api. All the methods you include there will automatically be exposed to Javascript.

Get Involved

Write about it
Make something with PHONK.app and tell me about it. I would love to know how you use it. (Github, e-mail, etc)
Have a look at the issues

Roadmap

~~Getting started guide~~
Improve documentation
How to contribute guide

License

This project is licensed under the terms of the GPL / LGPL v3 License. You can check out the full LICENSE description on the file LICENSE.txt.
