A collection of research papers on SRAM-based compute-in-memory architectures.

SRAM-Based Compute-In-Memory

Compute-in-memory has attracted growing attention in the AI era. Among different types of memory, SRAM features high speed, precision, and compatibility with digital CMOS technology. Here is a collection of recent work on SRAM-based compute-in-memory. Most of these work focuses on AI acceleration.

List of Papers

2023 ISSCC

  • (7.1) A 22nm 832Kb Hybrid-Domain Floating-Point SRAM In-Memory-Compute Macro with 16.2-70.2TFLOPS/W for High-Accuracy AI-Edge Devices [Floating-point, hybrid-domain for multiplication]
  • (7.2) A 28nm 64-kb 31.6-TFLOPS/W Digital-Domain Floating-Point-Computing-Unit and Double-Bit 6T-SRAM Computing-in-Memory Macro for Floating-Point CNNs [Floating-point, double-bitcell, approximation]
  • (7.3) A 28nm 38-to-102-TOPS/W 8b Multiply-Less Approximate Digital SRAM Compute-In-Memory Macro for Neural-Network Inference
  • (7.4) A 4nm 6163-TOPS/W/b 4790-TOPS/mm2/b SRAM Based Digital-Computing-in-Memory Macro Supporting Bit-Width Flexibility and Simultaneous MAC and Weight Update
  • (7.5) A 28nm Horizontal-Weight-Shift and Vertical-Feature-ShiftBased Separate-WL 6T-SRAM Computation-in-Memory Unit-Macro for Edge Depthwise Neural-Networks
  • (7.6) A 70.85–86.27TOPS/W PVT-Insensitive 8b Word-Wise ACIM with Post-Processing Relaxation
  • (7.7) CV-CIM: A 28nm XOR-Derived Similarity-Aware Computation-in-Memory for Cost-Volume Construction
  • (7.8) A 22nm Delta-Sigma Computing-In-Memory (ΔΣCIM) SRAM Macro with Near-Zero-Mean Outputs and LSB-First ADCs Achieving 21.38TOPS/W for 8b-MAC Edge AI Processing
  • (7.9) CTLE-Ising: A 1440-Spin Continuous-Time Latch-Based Ising Machine with One-Shot Fully-Parallel Spin Updates Featuring Equalization of Spin States
  • (16.1) MulTCIM: A 28nm 2.24μJ/Token Attention-Token-Bit Hybrid Sparse Digital CIM-Based Accelerator for Multimodal Transformers
  • (16.2) A 28nm 53.8TOPS/W 8b Sparse Transformer Accelerator with In-Memory Butterfly Zero Skipper for Unstructured-Pruned NN and CIM-Based Local-Attention-Reusable Engine
  • (16.3) A 28nm 16.9-300TOPS/W Computing-in-Memory Processor Supporting Floating-Point NN Inference/Training with Intensive-CIM Sparse-Digital Architecture [Floating-point, computation division]
  • (16.4) TensorCIM: A 28nm 3.7nJ/Gather and 8.3TFLOPS/W FP32 Digital-CIM Tensor Processor for MCM-CIM-Based Beyond-NN Acceleration [Floating-point, chiplet]
  • (16.7) A 40-310TOPS/W SRAM-Based All-Digital Up to 4b In-Memory Computing Multi-Tiled NN Accelerator in FD-SOI 18nm for Deep-Learning Edge Applications
  • (29.1) A 32.5mW Mixed-Signal Processing-in-Memory-Based k-SAT Solver in 65nm CMOS with 74.0% Solvability for 30-Variable 126-Clause 3-SAT Problems
  • (29.2) Snap-SAT: A One-Shot Energy-Performance-Aware All-Digital Compute-in-Memory Solver for Large-Scale Hard Boolean Satisfiability Problems

2023 MICRO

  • MAICC: A Lightweight Many-core Architecture with In-Cache Computing for Multi-DNN Parallel Inference

2023 DAC

  • PIM-HLS: An Automatic Hardware Generation Tool for Heterogeneous Processing-In-Memory-based Neural Network Accelerators
  • AutoDCIM: An Automated Digital CIM Compiler

2023 ASPLOS

  • Infinity Stream: Portable and Programmer-Friendly In-/Near-Memory Fusion [Compiler]

2023 HPCA

  • EVE: Ephemeral Vector Engines [General-purpose]

2023 JSSC

  • (Extension version of F. Tu et al. ISSCC, pp. 254-255, 2022) ReDCIM: Reconfigurable Digital Computing- In -Memory Processor With Unified FP/INT Pipeline for Cloud AI Acceleration
  • A Charge Domain SRAM Compute-in-Memory Macro With C-2C Ladder-Based 8-Bit MAC Unit in 22-nm FinFET Process for Edge Inference
  • (Extension version) A Floating-Point 6T SRAM In-Memory-Compute Macro Using Hybrid-Domain Structure for Advanced AI Edge Chips
  • (Extension version of F. Tu et al. ISSCC, pp. 466-467, 2022) TranCIM: Full-Digital Bitline-Transpose CIM-based Sparse Transformer Accelerator With Pipeline/Parallel Reconfigurable Modes

2023 TC

  • VSPIM: SRAM Processing-in-Memory DNN Acceleration via Vector-Scalar Operations

2023 TCAD

  • SDP: Co-Designing Algorithm, Dataflow, and Architecture for In-SRAM Sparse NN Acceleration [SW/HW co-design]

2022 ISSCC

  • (11.5) Single-Mode CMOS 6T-SRAM Macros with Keeper-Loading-Free Peripherals and Row-Separate Dynamic Body Bias Achieving 2.53fW/bit Leakage for AIoT Sensing Platforms
  • (11.6) A 5-nm 254-TOPS/W 221-TOPS/mm2 Fully-Digital Computing-in-Memory Macro Supporting Wide-Range Dynamic-Voltage-Frequency Scaling and Simultaneous MAC and Write Operations
  • (11.7) A 1.041-Mb/mm2 27.38-TOPS/W Signed-INT8 Dynamic-Logic-Based ADC-less SRAM Compute-In-Memory Macro in 28nm with Reconfigurable Bitwise Operation for AI and Embedded Applications
  • (11.8) A 28nm 1Mb Time-Domain Computing-in-Memory 6T-SRAM Macro with a 6.6ns Latency, 1241GOPS and 37.01TOPS/W for 8b-MAC Operations for Edge-AI Devices
  • (15.3) COMB-MCM: Computing-on-Memory-Boundary NN Processor with Bipolar Bitwise Sparsity Optimization for Scalable Multi-Chiplet-Module Edge Machine Learning
  • (15.5) A 28nm 29.2TFLOPS/W BF16 and 36.5TOPS/W INT8 Reconfigurable Digital CIM Processor with Unified FP/INT Pipeline and Bitwise In-Memory Booth Multiplication for Cloud Deep Learning Acceleration [Floating-point, pre-alignment]
  • (15.6) DIANA: An End-to-End Energy-Efficient DIgital and ANAlog Hybrid Neural Network SoC
  • (16.1) DIMC: 2219TOPS/W 2569F2/b Digital In-Memory Computing Macro in 28nm Based on Approximate Arithmetic Hardware
  • (29.3) A 28nm 15.59μJ/Token Full-Digital Bitline-Transpose CIM-Based Sparse Transformer Accelerator with Pipeline/Parallel Reconfigurable Modes [Transpose SRAM]

2022 VLSI

  • A 12nm 121-TOPS/W 41.6-TOPS/mm2 All Digital Full Precision SRAM-based Compute-in-Memory with Configurable Bit-width For AI Edge Applications

2022 MICRO

  • Multi-Layer In-Memory Processing [Compiler]

2022 DAC

  • Processing-in-SRAM acceleration for ultra-low power visual 3D perception [Visual odometry]

2022 GLSVLSI

  • Energy-Efficient In-SRAM Accumulation for CMOS-based CNN Accelerators

2022 JSSC

  • Two-Way Transpose Multibit 6T SRAM Computing-in-Memory Macro for Inference-Training AI Edge Chips

2022 TC

  • Eidetic: An In-Memory Matrix Multiplication Accelerator for Neural Networks

2021 ISSCC

  • (15.1) A Programmable Neural-Network Inference Accelerator Based on Scalable In-Memory Computing [Charge-domain]
  • (15.2) A 2.75-to-75.9TOPS/W Computing-in-Memory NN Processor Supporting Set-Associate Block-Wise Zero Skipping and Ping-Pong CIM with imultaneous Computation and Weight Updating
  • (15.4) A 5.99-to-691.1TOPS/W Tensor-Train In-Memory-Computing Processor Using Bit-Level-Sparsity-Based Optimization and Variable-Precision Quantization
  • (16.3) A 28nm 384kb 6T-SRAM Computation-in-Memory Macro with 8b Precision for AI Edge Chips
  • (16.4) An 89TOPS/W and 16.3TOPS/mm2 All-Digital SRAM-Based Full-Precision Compute-In Memory Macro in 22nm for Machine-Learning Edge Applications [TSMC]

2021 VLSI

  • A 13.7 TFLOPS/W Floating-point DNN Processor using Heterogeneous Computing Architecture with Exponent-Computing-in-Memory [Floating-point]
  • PIMCA: A 3.4-MB Programmable In-Memory Computing Accelerator in 28nm For On-Chip DNN Inference

2021 ASSCC

  • A 16Kb Transpose 6T SRAM In-Memory-Computing Macro based on Robust Charge-Domain Computing

2021 JSSC

  • (Extension version of X. Si et al. ISSCC, pp. 246-248, 2020) A Local Computing Cell and 6T SRAM-Based Computing-in-Memory Macro With 8-b MAC Operation for Edge AI Chips

2020 ISSCC

  • (15.2) A 28nm 64Kb Inference-Training Two-Way Transpose Multibit 6T SRAM Compute-in-Memory Macro for AI Edge Chips
  • (15.3) A 351TOPS/W and 372.4GOPS Compute-in-Memory SRAM Macro in 7nm FinFET CMOS for Machine-Learning Applications
  • (15.5) A 28nm 64Kb 6T SRAM Computing-in-Memory Macro with 8b MAC Operation for AI Edge Chips

2020 DAC

  • Bit parallel 6T SRAM in-memory computing with reconfigurable bit-precision [BL boosting]

2020 ISCAS

  • Towards a Reconfigurable Bit-Serial/Bit-Parallel Vector Accelerator using In-Situ Processing-In-SRAM

2020 JSSC

  • A Programmable Heterogeneous Microprocessor Based on Bit-Scalable In-Memory Computing
  • (extension version of J. Wang et al. ISSCC, pp. 224-226, 2019) A 28-nm Compute SRAM With Bit-Serial Logic/Arithmetic Operations for Programmable In-Memory Vector Computing [General-purpose]

2020 TC

  • CIMAT: A Compute-In-Memory Architecture for On-chip Training Based on Transpose SRAM Arrays [Transpose SRAM]

2020 SSC-L

  • A 35.6 TOPS/W/mm² 3-Stage Pipelined Computational SRAM With Adjustable Form Factor for Highly Data-Centric Applications

2019 ISSCC

  • (7.5) A 65nm 0.39-to-140.3TOPS/W 1-to-12b Unified NeuralNetwork Processor Using Block-Circulant-Enabled Transpose-Domain Acceleration with 8.1× Higher TOPS/mm2 and 6T HBST-TRAM-Based 2D Data-Reuse Architecture [Transpose SRAM]
  • (14.2) A Compute SRAM with Bit-Serial Integer/Floating-Point Operations for Programmable In-Memory Vector Acceleration [General-purpose, floating-point, transpose SRAM]
  • (24.5) A Twin-8T SRAM Computation-In-Memory Macro for Multiple-Bit CNN-Based Machine Learning

2019 ISCA

  • Duality cache for data parallel acceleration [Compiler]

2019 HPCA

  • Bit Prudent In-Cache Acceleration of Deep Convolutional Neural Networks

2019 ESSCIRC

  • A 1-16b Precision Reconfigurable Digital In-Memory Computing Macro Featuring Column-MAC Architecture and Bit-Serial Computation

2019 JSSC

  • A 64-Tile 2.4-Mb In-Memory-Computing CNN Accelerator Employing Charge-Domain Compute [Charge-domain]

2019 TVLSI

  • 8T SRAM Cell as a Multibit Dot-Product Engine for Beyond Von Neumann Computing

2018 ISSCC

  • (31.1) Conv-RAM: An energy-efficient SRAM with embedded convolution computation for low-power CNN-based machine learning applications
  • (31.2) A 42pJ/Decision 3.12TOPS/W Robust In-Memory Machine Learning Classifier with On-Chip Training
  • (31.5) A 65nm 4Kb Algorithm-Dependent Computing-in-Memory SRAM Unit-Macro with 2.3ns and 55.8TOPS/W Fully Parallel Product-Sum Operation for Binary DNN Edge Processors

2018 ISCA

  • PROMISE: An End-to-End Design of a Programmable Mixed-Signal Accelerator for Machine-Learning Algorithms
  • Neural Cache: Bit-Serial In-Cache Acceleration of Deep Neural Networks
  • Bit Fusion: Bit-Level Dynamically Composable Architecture for Accelerating Deep Neural Network

2018 JSSC

  • Recryptor: A Reconfigurable Cryptographic Cortex-M0 Processor With In-Memory and Near-Memory Computing for IoT Security

2017 ISSCC

  • (14.6) A 0.62mW ultra-low-power convolutional-neural-network face-recognition processor and a CIS integrated with always-on haar-like face detector [Transpose SRAM]

2017 MICRO

  • Cache Automaton

2017 HPCA

  • Compute Caches

2017 JSSC

  • In-Memory Computation of a Machine-Learning Classifier in a Standard 6T SRAM Array

2016 JSSC

  • A 28 nm Configurable Memory (TCAM/BCAM/SRAM) Using Push-Rule 6T Bit Cell Enabling Logic-in-Memory
