Blazingly fast path based retained layout engine for Bevy entities, built around vanilla Bevy ECS. This library is intended to replace the existing bevy_ui crate, but nothing is stopping you from using them both at the same time.

It uses a combination of Bevy's built-in hierarchy and its own custom hierarchy to give you the freedom of control without the bloat or borrow checker limitations usually faced when creating UI.

It gives you the ability to make your own custom UI using regular ECS like every other part of your app.

TLDR: It positions your entities as HTML objects for you, so you can slap custom rendering or images on them.

^ A recreation of Cyberpunk UI in Bevy. (Source code here).

Description

Note

This library is EXPERIMENTAL.

Bevy_Lunex is built on a simple concept: to use Bevy's ECS as the foundation for UI layout and interaction, allowing developers to manage UI elements as they would any other entities in their game or application as opposed to bevy_ui.

Path-Based Hierarchy: Inspired by file system paths, this approach allows for intuitive structuring and nesting of UI elements. It's designed to make the relationship between components clear and manageable, using a syntax familiar to most developers, while also avoiding the safety restrictions Rust enforces (as they don't help but instead obstruct for UI).
Retained Layout Engine: Unlike immediate mode GUI systems, Bevy_Lunex uses a retained layout engine. This means the layout is calculated and stored, reducing the need for constant recalculations and offering potential performance benefits, especially for static or infrequently updated UIs.
ECS friendly: Since it's built with ECS, you can extend or customize the behavior of your UI by simply adding or modifying components. The scripting is done by regular systems and callbacks are done using events.
2D & 3D UI: One of the features of Bevy_Lunex is its support for both 2D and 3D UI elements, leveraging Bevy's Transform component. This opens up a wide range of possibilities for developers looking to integrate UI elements seamlessly into both flat and spatial environments.
Mod picking: For interactions, we intagrate with bevy_mod_picking, which is getting upstreamed into Bevy. Lunex also provides custom picking backend, you just need add "picking" feature.

Workflow

First, we need to define a component, that we will use to mark all entities that will belong to our ui system.

#[derive(Component)]
pub struct MyUiSystem;

Then we need to add UiPlugin with our marker component. The NoData generics are used if you need to store some data inside the nodes.

fn main() {
    App::new()
        .add_plugins(DefaultPlugins)
        .add_plugins(UiPlugin::<MyUiSystem>::new())
        .run();
}

By marking any camera with MyUiSystem, it will pipe its size into our future UI system entity.

commands.spawn((
    MyUiSystem,
    Camera2dBundle {
        transform: Transform::from_xyz(0.0, 0.0, 1000.0),
        ..default()
    }
));

Now we should create our entity with the UI system. The base componets are UiTree + Dimension + Transform. The UiTreeBundle already contains these components. The newly introduced Dimension component is used as the source size for the UI system. We also need to add the MovableByCamera component so our entity will receive updates from camera. The last step is adding our MyUiSystem type as a generic.

commands.spawn((
    UiTreeBundle::<MyUiSystem> {
        tree: UiTree::new("MyUiSystem"),
        ..default()
    },
    MovableByCamera,
)).with_children(|ui| {
    // Here we will spawn our UI in the next code block ...
});

Now, any entity with UiLayout + UiLink spawned as a child of the UiTree will be managed as a UI entity. If it has a Transform component, it will get aligned based on the UiLayout calculations taking place in the parent UiTree. If it has a Dimension component then its size will also get updated by the UiTree output. This allows you to create your own systems reacting to changes in Dimension and Transform components.

You can add a UiImage2dBundle to the entity to add images to your widgets. Or you can add another UiTree as a child, which will use the computed size output in Dimension component instead of a Camera piping the size to it.

ui.spawn((
    UiLink::<MyUiSystem>::path("Root"),
    UiLayout::Window::FULL.pos(Ab(20.0)).size(Rl(100.0) - Ab(40.0)).pack(),
));

ui.spawn((
    UiLink::<MyUiSystem>::path("Root/Rectangle"),
    UiLayout::Solid::new().size(Ab((1920.0, 1080.0))).pack(),
    UiImage2dBundle::from(assets.load("background.png")),
));

UiLink is what is used to define the the custom hierarchy. It uses / as the separator. If any of the names don't internally exist inside the parent UiTree, it will create them.

As you can see in the terminal (If you have added a UiDebugPlugin), the final structure looks like this:

> MyUiSystem == Window [pos: (x: 0, y: 0) size: (x: 100%, y: 100%)]
    |-> Root == Window [pos: (x: 20, y: 20) size: (x: -40 + 100%, y: -40 + 100%)]
    |    |-> Rectangle == Solid [size: (x: 1920, y: 1080) align_x: 0 align_y: 0]

Quite simple, isn't it? Best part is that by relying on components only, you are potentially able to hot-reload UI or even stream UI over the network. The downside is that by relying on strings to link entities, we are giving up some safety that Rust provides. But I am all for using the right tools for the right task. By putting away some safety, we can skip the bothersome bloat that would otherwise be required for such application.

Nodes & Units

There are multiple nodes in UiLayout.

Boundary - Defined by point1 and point2, it is not influenced by UI flow and is absolutely positioned.
Window - Defined by point and size, it is not influenced by UI flow and is absolutely positioned.
Solid - Defined by size only, it will scale to fit the parenting node. It is not influenced by UI flow.
Div - Defined by padding & margin. Dictates the UI flow. It uses styleform paradigm, very similar to HTML.

Warning

Div is not finished, it's WIP, please refrain from using it.

This library comes with several UI units. They are:

Ab - Stands for absolute, usually Ab(1) = 1px
Rl - Stands for relative, it means Rl(1.0) == 1%
Rw - Stands for relative width, it means Rw(1.0) == 1%w, but when used in height field, it will use width as source
Rh - Stands for relative height, it means Rh(1.0) == 1%h, but when used in width field, it will use height as source
Em - Stands for size of symbol M, it means Em(1.0) == 1em, so size 16px if font size is 16px
Sp - Stands for remaining space, it's used as proportional ratio between margins, to replace alignment and justification. Only used by Div
Vp - Stands for viewport, it means Vp(1.0) == 1v% of the UiTree original size
Vw - Stands for viewport width, it means Vw(1.0) == 1v%w of the UiTree original size, but when used in height field, it will use width as source
Vh - Stands for viewport height, it means Vh(1.0) == 1v%h of the UiTree original size, but when used in width field, it will use height as source

Warning

Sp is not finished, it's WIP, please refrain from using it.

Versions

Bevy	Bevy Lunex
0.13.2	0.1.0 - latest
0.12.1	0.0.10 - 0.0.11
0.12.0	0.0.7 - 0.0.9
0.11.2	0.0.1 - 0.0.6

Warning

Any version below 0.0.X is experimental and is not intended for practical use.

Contributing

Any contribution submitted by you will be dual licensed as mentioned below, without any additional terms or conditions. If you have the need to discuss this, please contact me.

Licensing

Released under both APACHE and MIT licenses. Pick one that suits you the most!
