Trajectory Prediction with Graph-based Dual-scale Context Fusion

Introduction

This is the project page of the paper

Lu Zhang, Peiliang Li, Jing Chen and Shaojie Shen, "Trajectory Prediction with Graph-based Dual-scale Context Fusion", 2021.

Preprint: Link

Quantitative Results:

Video:

Supplementary Video (Argoverse Tracking dataset):

Demo

Color scheme: green - predicted trajectories; red - observation & GT trajectories; orange - other agents.

Have a try!

Install dependencies

Create a new conda env

conda create --name dsp python=3.8
conda activate dsp

Install PyTorch according to your CUDA version. For RTX 30 series, we recommend CUDA >= 11.1, PyTorch >= 1.8.0.

conda install pytorch==1.10.1 torchvision==0.11.2 torchaudio==0.10.1 cudatoolkit=11.3 -c pytorch -c conda-forge

Install Argoverse API, please follow this page.
Install other dependencies

pip install scikit-image IPython tqdm ipdb tensorboard

Install PyTorch Scatter, please refer to this page.

Play with pretrained models

Generate a subset of the dataset for testing using the script (it will generate 1k samples):

bash scripts/argo_preproc_small.sh

Download the pretrained model (Google) (Baidu, code: tmnz). Move the pretrained model to ./saved_models/, then use the scripts below to get prediction results:

bash scripts/argo_dsp_vis.sh

Since we store each sequence as a single file, the system may raise error OSError: [Erron 24] Too many open files during evaluation and training. You may use the command below to solve this issue:

ulimit -SHn 51200
ulimit -s unlimited

Train from scratch

Preprocess Argoverse motion forecasting dataset using the script:

bash scripts/argo_preproc_all.sh

Note that the preprocessed dataset is pretty large (~ 90 GB), please reserve enough space for preprocessing.

Launch (single-card) training using the script:

bash scripts/argo_dsp_train.sh

Citation

If you find this paper useful for your research, please consider citing the following:

@article{zhang2021trajectory,
  title={Trajectory Prediction with Graph-based Dual-scale Context Fusion},
  author={Zhang, Lu and Li, Peiliang and Chen, Jing and Shen, Shaojie},
  journal={arXiv preprint arXiv:2111.01592},
  year={2021}
}

Acknowledgement

We would like to express sincere thanks to the authors of the following tools and packages:

ydcttt/DSP
